1. Safe and Reliable
IP 54 protection, Bulit-in electric leakage protection
2. Integrated Design for PV and Energy Storage
Integrated PV and energy storage, equipped with UPS functional, supporting various kinds of batteries.
Max Efficiency >98.2%, Smart MPPT, tracing efficiency up to 99.99%.
4. Multi Parallel Operation
Max 15 pcs in Parallel
5. Flexible Communications
Support App RS485/Wifi
Model No. | HLS-Inverter-06/08/10T |
PV Input | |
| Max.PV input power(W) | 13000 |
| Max. PV input voltage(V) | 1000 |
| MPPT Operation Voltage Range(V) | 180-950 |
| MPPT Number Of Ways/ Strings | 2/1 |
| Battery Parameters | |
Max Input/Output Voltage | 550 |
Operating Voltage Range(V) | 25/30 |
Max Charge/ DischargeCurrent(d.c.A) | 180-550 |
Max Input/Output Power | 8000 |
| AC Parameters (On Grid) | |
Rated Power (W) | 10000 |
Max Apparent Power | 10000 |
Rated Voltage (Vac) | 380,3L/N/PE |
Rated Frequency (Hz) | 50/60 |
Max Output Current (A) | 15 |
Power Factor Range | ~1(0.8advance~0.8lag settable) |
| Total Harmonic Distortion Of Current (@ Rated Power) | <3% |
| AC Output Parameters(Off-Grid) | |
| Rated Output Power (W) | 10000 |
Max Apparent Output Power | 10000 |
Rated Output Voltage(Vac) | 380,3L/N/PE |
| Rated Output Frequency(Hz) | 50/60 |
| Max Output Current (A) | 15 |
| Basic Parameters | |
| Operating Temperature Range | '-25ºC...+60ºC(>45ºC derating) |
| Working Altitude (m) | <4000 derating |
| Noise Index(dB) | <40 |
| Topological Structure | transformerless isolation |
| Type Of Cooling | free convection |
| Protection Class | IP65 |
| Relative Humidity Range | 0~100% without condensation |
| DC Connector Type | MC/Amphenol/phoenix |
| AC Connector Type | plug-in connector |
| Man-Machine Interaction Mode | LCD |
| Cloud Communication Mode | RS485(WiFi/GPRS selectable) |
| BMS Communication Mode | CAN |
| Electric Meter Communication Mode | RS485 |
| Installation Method | wall-mounted |
| Size(W*D*H)(mm) | 505*570*220 |
| Weight(kg) | 23 |
| Max Efficiency | >98.2% |
Certificates | IEC61000/IEC62109 EN50549 VDE-AR-N 4105:2018 EN50549-1:2019+AC:2019-04 IEC62109,AS62040.1,AS/NZS4777.2 AS4777.2, NRS097-2-1:2017 |
Hunan Hyliess New Energy Technology is a high-tech manufacturer with our own brand Hyliess, which was established in April 2015 with the registered capital of 4.5 million USD, located in Changsha China. The company focus on R&D, production and sales of new energy technology. We have the most advanced R&D and manufacturing equipment in hydrogen and lithium energy storage products.
8 Years of experience in the new energy power industry.
Residential solar energy storage system
Commercial use solar energy on/off grid system solution
Industrial solar energy storage on/off grid system solution
Micro-grid off-grid system solution
Cooperate with top universities to form a R&D team with more than 70 specialists.
Obtained 38 patents in lithium battery sector and hydrogen energy sector.
More than 100,000m2 meters factory area .
5GWh Energy storage products' annual output value.
1. Are you a Manufacturer? What is your products?
We are a professional high-tech manufacturer with our own brand Hyliess, which was established in April 2015, with the registered capital of 4.5 million USD.
Products: Hybrid Inverters, Residential Energy Storage Systems, Commercial & Industrial Energy Storage Systems, EV Charger ...
2. What' s your MOQ?
No limited. Small order also welcome.More quantity has better price, we will check the best price for you.
3. How to get a sample?
Please provide us your address and contact info to receive a sample. After receiving your payment, we will send out the product as soon as possible.
4. Do you have OEM or ODM service?
Yes, of course. OEM & ODM service is warmly provided.
5. What's your advantage?
8 Years of experience in the new energy power industry.
Commercial use solar energy on/off grid system solution
Industrial solar energy storage on/off grid system solution
Micro-grid off-grid system solution
Cooperate with top universities to form a R&D team with more than 70 specialists.
Obtained 38 patents in lithium battery sector and hydrogen energy sector.
More than 100,000m2 meters factory area .
5GWh Energy storage products' annual output value.
