Double Dolly Full Trailer
24
24
Full Trailer
15-80t
ISO9001, CCC, ISO/TS16949
8000-9000mm
2240mm
Medium Duty
Trailing Arm Type
Stake
Customized 2 -6 Axles
6\10\12/24
Not Self-dumping
ABS Anti-lock Braking System
Steel
New
Color Advised by Client
DRZE
by Bulk Cargo Carrier, Roro or Frt Container
Customization
Hubei China
8716399000
Product Description
Customized 4 -6 Axles Double Dolly Full Trailer With 5Th Wheels (Interlink Trailer)
Customized 2-6 Axles Drawbar Full Trailer Dolly Trailer ( Cargo Stake 40T -60T)
Superlink/ Interlink Double Box Semi Trailer for Heavy Duty Cargo Transporter
Superlink Interlink 4axle Side Panel Container Semi Trailer
DOLLY Tanker, Fuel Tanker's Pup Trailer,Pup Trailer Tankers, FULL trailer, pup trailer, Tank Dolly, Tank Dolly trailer Drawbar Fulltowing Trailer Trailer Dolly for Sale
4 Wheels Mini Dump Drawbar Full Towing Dolly Trailer
Customized 2-6 Axles Drawbar Full Trailer Dolly Trailer ( Cargo Stake 40T -60T)
Double Combination Interlink 2 -6 Axle Dolly Trailer
Superlink Truck Bodies Interlink Semi TrailerSuperlink/ Interlink Double Box Semi Trailer for Heavy Duty Cargo Transporter
Superlink Interlink 4axle Side Panel Container Semi Trailer
| Items | Flatbed semi trailer |
| Loading Capacity | 40-80 tons |
| Axle | 3/4 pieces, 13T FUWA/BPW/QUEST axle |
| Tyre | 12/16 pieces, 12.00R20 |
| Dimensions(LxWxH) | 12500 -17000mm x 2500 x 1550mm |
| Tare weight | 7 -9TONS |
| Axle spacing | 1310mm |
| Rims | 8.5-20, 9.0-20 |
| Suspension System | Leaf spring suspension / air suspension |
| Brake System | Dual line pneumatic brake system with WABCO emergency relay valve |
| Main Beam | Height 500mm Q345 carbon steel |
| Chassis | upper 20mm, lower 20mm. Mid web 12mm |
| Side wall height | 600mm standard,600-1500mm available |
| Twist locks | 12 units,THT brand |
| Kingpin | 2' or 3.5' interchangeable,JOST brand |
| Landing Gear | 28 Tons , Two speed manual operation |
| Electrical System | 1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) German standard |
| Lights and Reflectors | Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light |
| Painting | Shot blast to SA 2.5 Standard prior to application of primer, polyurethane top coat. Total not less than 100μm;Any color will be available |
| Tool Box | One tool box with a set of standard trailer tools |
| Spare Tyre Carrier | One piece or two pieces |
Superlink Interlink 4axle Side Panel Container Semi Trailer
| Specification | ||
| Name | front side wall trailer with tractor seat 2 axle 40 ton | |
| Model | DRZ9400P | |
| Overall dimension | 10500 *2500 * 1550mm | |
| Loading capacity | 40T | |
| Axle brand and number | 13TFuwa Brand, 2units | |
| Wheel base(mm) | 6880+1310 | |
| Kingpin | 50# or 90# | |
| Tractor seat | 50# or 90# | |
| Steel Spring | 10/10 leaf spring suspension | |
| The material of Main beam | The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm, middle plate is 8mm. | |
| Tyre and quantity | 12R22.5 12pieces | |
| Landing gear | 28T, double speed operation | |
| Platform plate | 3mm Checkered steel plate | |
| Brake system | Dual Line braking system ,none ABS. | |
| Brake air chamber | Four double and two single chamber | |
2 -6Axles Dolly Full Trailer With Draw Bar For Sale
DOLLY Tanker, Fuel Tanker's Pup Trailer,Pup Trailer Tankers, FULL trailer, pup trailer, Tank Dolly, Tank Dolly trailer Drawbar Fulltowing Trailer Trailer Dolly for Sale
4 Wheels Mini Dump Drawbar Full Towing Dolly Trailer
| Overall Dimension | 9000*2500*3500mm or Customized |
| Curb Weight | 5.0T |
| Loading Capacity | 40T |
| Main Beam Spec. | T700/Q345 Steel, Height:500mm, Plate Thickness:8-16mm |
| Side Frame | Channel Steel |
| Cross Brace | Channel Steel/Bending Steel |
| Suspension | Mechanical Suspension, Air Suspension or Optional/ Tandem or Single Suspension |
| Leaf Spring | 10-layers leaf spring(90mm*13mm*10pcs) |
| Axle Spec. | 13T/16T/20T BPW or FUWA brand |
| King Pin | 2"(50mm)or3.5"(90mm) JOST Brand |
| Tire | 11.00R20/12.00R20/ 12R22.5 |
| Brake Chamber | 2sets |
| Electric System | 24V, One Set 6-core Standard Cable |
| Light | Tail lamp with turn signal,brake light & reflector,side lamp etc |
| Painting | Sand blasting, prime coating, surface painting,color optional, wax polishing |
| Packing | FCL Container, Ro-ro Shipment or Optional |
Axle:
Famous Brand Axle Support
Trailer Durable and High Truck Attendance Rate
Chassis:
China Best Q345B-T700 support Stronger Main Beam
Tire:
Good Quality Tire support Trailer Running Safety&Smoothly
King Pin:
JOST Detachable Type support Durable and Fast&Easy Replace
Emergency Valve:
Fast Response,Low Failure support Safetly&Protect Tire Longer Time Use
Parameters:
Overall Dimension | 13000*3000*3100mm or Customized | ||
Curb Weight | 6.5T | ||
Loading Capacity | 40T, 50T, 60T, 70T, 80T, 90T, 100T | ||
Main Beam Spec. | T700/Q345 Steel, Height:500mm, Plate Thickness:8-16mm | ||
Side Frame | Channel Steel | ||
Cross Brace | Channel Steel/Bending Steel | ||
Suspension | Mechanical Suspension, Air Suspension or Optional | ||
Leaf Spring | 10-layers leaf spring(90mm*13mm*10pcs) | ||
Axle Spec. | 13T/16T/20T BPW or FUWA brand | ||
King Pin | 2"(50mm)or3.5"(90mm) JOST Brand | ||
Tire | 11.00R20/12.00R20/ 12R22.5 | ||
Brake Chamber | 6sets | ||
Landing Gear | 28T*2, JOST brand | ||
Accessories | 1 Standard Tool Box | ||
Electric System | 24V, One Set 6-core Standard Cable | ||
Light | Tail lamp with turn signal,brake light & reflector,side lamp etc | ||
Painting | Sand balsting,prime coating, surface painting,color opitional, wax polishing | ||
Ladder | Spring or Hydraulic | ||
Packing | FCL Container, Ro-ro Shipment, Framework or Optional | ||
