Product Description
I.SINOTRUK HOWO 20FT 40FT Container Side Lifter Truck for Self-loadingContainer
Container side loaders make it easier to lift a container up, so it is possible to avoid damage to the container
(unlike using a container flatbed trailer only). Side loaders can slide to fit 20ft-40ft containers with a safety
control (stop button). The front and rear cranes can work together and separately, making it easy and convenient
to adjust the container. The container side lifter adapt to many sizes of container and greatly reduce the workload
of unloading a container. This product is widely used in the main ports of the world. In the future, the demand for container side loaders will continue to grow.
II. Specs of SINOTRUK HOWO 20FT 40FT Container Side Lifter Truck for
Self-loading Container
| TECHNICAL SPECIFICATION | ||||||
| Chassis Specification | ||||||
| Main specification | Chassis brand | SINOTRUK HOWO | ||||
| Overall dimension(L*W*H) | 10965mm*2500mm*3780mm | |||||
| Truck Chassis | Cab | HW76 new face, flat-roof, air-conditioner and heater, defrosting, AM/FM radio, ashtray, electric windows, 4-point hydraulic suspension cab, etc | ||||
| Drive type | 8x4, Left hand drive or Right hand drive | |||||
| Gross Weight | 31 tons | |||||
| Wheelbase | 1800+4600+1350 mm | |||||
| Tyre size & number | 12R22.5, 12pcs | |||||
| Axles | HF9/ HC16 | |||||
| Transmission | HW19710, 10F+2R | |||||
| Engine | WD615.47 | |||||
| Engine horsepower | 371HP | |||||
| Engine Emission Standard | Euro 2, diesel | |||||
| Engine Type | 6 cylinders in-line, turbo-charged | |||||
| Steering | Power-assissted steering | |||||
| Brakes | Two-circuit air brake | |||||
| Color | Processed with anti-corrosive primer, and customized color | |||||
| Side Lifter Specification | ||||||
| Model | MQH37A | Max. lifting capacity | 37 tons | |||
| Max. stabilizer outreach | 3200 mm | Application | Load and unload of 20FT container | |||
| Overall Width | 2500 mm | Max. working range | 4000 mm | |||
| Overall length | 1020 mm | Overall height | 2490 mm | |||
| Container Size | 6.2x2.2x2.2 m | Max. Pressure of hydraulic system | 28MPa | |||
