Fire truck also called fire tanker,fire engine ,fire appatatus ,water fire truck ,foam fire truck ,fire rescue truck) is a vehicle designed primarity for fire fighting operations-to extinguish fire efficientyly to prevent fire spread ,reducing the loss caused by fire maximumly.
Fire fighting truck can be divided into many types:
a. According to vehicle size ,there are mini fire fighting truck ,light fire fighting truck ,medium fire fighting truck ,heavy-duty fire fighting truck;
b. According to chassis drive type ,there are 4x2 fire fighitng truck ,6x4 fire fighting truck ,8x4 fire fighitng truck and off-road type 4x4,6x6 fire truck;
c. According to chassis brand,ther are I-SUZU ,Dongfeng,FOTON,FAW ,SINOTRUCK ,etc.
d. According to fire agent,there are water tank fire fighting truck ,water/foam fire fighting truck ,dry powder fire fighting truck
II. Details of I SUZU GIGA 380HP EURO 4 Fire Truck 12Tons Foam Fire Truck Manufacturer from China
III.Specification of I SUZU GIGA 380HP EURO 4 Fire Truck 12Tons Foam Fire Truck Manufacturer from China
| 6x4 Japan brand heavy duty water &foam & dry powder fire apparatus, 10,000L water tank & 2,000L foam tank & 1,000L dry powder fire trucks price | |||
| Vehicle Parameters | |||
| General | Vehicle Model | VLT5243 | |
| Vehicle Brand | FUYA | ||
| Chassis Brand | (QL1250U1SDZY) | ||
| Overall Dimension(mm) | 9550×2500×3500 | ||
| GVW/Curb Weight(kg) | 23740/12390/10900 | ||
| Chassis Parameters | |||
| Cab | Cab Seat | 3+3 | |
| Air Conditioner | YES | ||
| Engine | Fuel Type | diesel | |
| Engie Model | 6UZ1-TCG51 | ||
| Engine Brand | I-SUZU | ||
| Power(kw/hp) | 257/350 | ||
| Displacement(cc) | 9839 | ||
| Emmission Standard | Euro 5 | ||
| Chassis | Drive Type | 6X4 | |
| Transmission | 8speed, Manual | ||
| Wheelbase(mm) | 4565+1370 | ||
| Tyre Specification | 315/80R22.5 | ||
| Tyre No.(pcs) | 10 | ||
| Max Speed(km/h) | 90 | ||
| Paint | Red | ||
| Fire Truck Water Tank Structure Parameters | |||
| Water Tank Volume | 10000L/ 2800 gallons | Tank Material | Carbon Steel |
| Foam Tank Volume | 2000L / 550 gallons | Tank Material | Carbon Steel |
| Dry Powder Volume | 1 ton | Nitrogen Cylinder | 70L/pcs,in total 3pcs |
| Tank Thickness | 4/3/3mm | Fire pump | CB10/60 |
| Fire monitor | PL48 | Color and Logo | Optional |
| Standard configuration | Chassis,sub frame, van body,national standard equipment box, 25 units national standard fire-fighting equipment,fire pump(CB10/60 according to the capacity), fire gun(PL48 according to the capacity),fire power take off, sliding gate, row type lights, reel, common tools,rear climbing ladder,water tank,foam tank, dry powder tank,nitrogen system | ||
IV.Fire Truck Details
V.Fire Truck Production workshop and testing
VI.SHIPMENT ( RORO or BULK VESSEL)
RORO: The truck is driven to the ship inside directly and fixed well. It can protect the truck being rusty and broken during shipping.
BULK: The truck is lifted by crane then put on the vessel deck. This model is much cheaper.
CONTAINER: The truck is put into the container. This model is used for small model trucks
The truck is driven to the ship inside directly and fixed well. It can protect the truck being rusty and broken during shipping.
VII. About us
HUBEI FUYA VEHICLE CO.,LTD is an authorized special truck manufacturer which has many years in design ,product ,sales and service in special trucks like as boom truck , fire truck, manlift truck, tank truck , garbage truck, tipper truck , wrecker truck , refrigerated truck and etc. Main info as below:
FAQ
Why choose us?
Experience
10 years experience of production,sales,research and development in the field of special trucks.
Specialization
We can produce according to your demand, the material,the size, the color and the logo is optional for you.
Good quality
Has solid technology, advanced equipments;Reliant quality and flexible modes of operation also have strict quality control system
and passed the ISO9001-2008 and the 3C (china compulsory certification),with sgs,bv certifcate as well.
Chassis supply
We have a very good long term cooperation relationship with chassis manufacturer,such as dongfeng,foton,sinotruck,shacman,
faw,hino,camc,north-benz,ect.
Production supply capacity
Company scale
More than 3000 employees with 1000 acres factory, total asset 2 billion.
We manufacture the truck as soon as possible once your order confirmed.And for the stock, we can delivery it immediately.
Any more information regarding to fire truck,please do not hesitate contact with us!
