JSXT102
Long Term Technical Support for Container Trailer
12 Months
Semi-Trailer
61.9cbm
ECE, GCC, CE, ISO9001, DOT, CCC, ISO/TS16949
8000-9000mm
1820mm
Heavy Duty
Cross Arm Type
Flatbed
3
12
Not Self-dumping
ABS Anti-lock Braking System
Q345r
New
LPG Tank Semi-Trailer
13590*2550*4000
18000
13230*2525
61.9cbm
JSXT
Consulting Customer Service
13590*2550*4000mm
China
Product Description
LPG tanker semi trailer is a special transport semi-trailer used to transport propane, propylene, dimethyl ether, liquid ammonia, methylamine, acetaldehyde and other liquefied gases. The liquefied gas transport semi-trailer can be divided into: two-axle liquefied gas transport semi-trailer, three-axle liquefied gas transport semi-trailer. The liquefied gas transport semi-trailer can be designed and modified according to the needs of customers, suitable for liquid ammonia, liquid sulfur dioxide, propylene, propane, liquefied petroleum gas, dimethyl ether, n-butane, isobutane, butene, isobutene, butadiene, cyclo Transport semi-trailer for most gases such as oxyethane.
Product Overview | |||
Transport medium | LPG | Volume | 61.9CBM |
Dimensions(mm) | 13590*2550*4000 | Tank size(mm) | 13230×Φ2525 |
Self weight(kg) | 18000 | Load(kg) | 26000 |
Tank material | Head:Q420R,Cylinder:Q345R | ||
Girder material | Q345R | ||
shape | Cylindrical | ||
Load mass(kg) | 26000 Propane density: 420KG/cubic meter | ||
Overall mass(kg) | 18000 | ||
Total mass(kg) | 44000 | ||
Head thickness | 18mm | ||
Tank thickness | 16mm | ||
King pin | 90# ( 3.5 inch ) | ||
Front/rear suspension(mm) | front: -, rear: 1800 | ||
Departure angle | front: -, rear: 16 | ||
suspension | Leaf spring - / 8 / 8/ 8 | ||
Leaf spring | Front 8, middle 8 and rear 8 | ||
Axle | Fuwa 13 tons | ||
Wheelbase (mm) | 7010+1310+1310 | ||
Number of tires | 12 | ||
Track(mm) | 1840/1840/1840 | ||
Tire specifications | 12R22.5 12PR | ||
Landing gear | 28T | ||
Brake | Drum type | ||
Braking System | Air brake | ||
Spare tire carrier | Have | ||
Light | Front position light, rear position light, rear tail light assembly, side return reflector | ||
Voltage | 24V | ||
Circuit socket | Have | ||
Toolbox | Have | ||
Colour | According to client requirements | ||
Hazard category | 2.1 | ||
UN number | UN1075 | ||
Design life | 15 years | ||
Safety valve form | Built-in full-open | ||
Safety valve pressure | 1.94MPa | ||
Safety valve rated discharge pressure | Less than or equal to 2.16MPa | ||
Safety valve return pressure | Greater than or equal to 1.75MPa | ||
Safety valve seat throat | 50mm | ||
Emergency shut-off device gas phase model | QGQJ43F-25P | ||
Emergency shut-off device liquid phase model | QGQJ43F-25P | ||
Emergency shut-off device operation | Manual mechanical control | ||
Pressure gauge model | YN-100Z | ||
Operating temperature | Negative 40 to 55 | ||
Hydrostatic test pressure | 2.34MPa | ||
Air tightness test pressure | 1.8MPa | ||
Level gauge model | UQZ-2.5P | ||
Level gauge form | Magnetic float | ||
Unloading device nominal diameter | DN50 | ||
Thermometer model | WSS-412 | ||
Thermometer accuracy | Level 1.5 | ||
Barrel corrosion allowance | 1.0mm | ||
Cylinder design pressure | 1.61MPa | ||
Q1. What's your MOQ? One unit trailer or truck.
Q2. Can you satisfy my special requirement?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
Q3. How about your product quality?
High quality has always been our advantage.We all use high quality brand materials with 100% quality assurance.
Q4. How can I get the price of your vehicle?
You can contact with us through any of the following contact information. Our personalized service person will respond you within 24hours.
Q5. Is it available to print our own brand on the vehicle? Totally acceptable as you wish.
24 hours online service.If you have any question,
you could contact us at your any time.
