A dump truck refers to a vehicle that unloads cargo by itself through hydraulic or mechanical lifting. Also called a dump truck. It is composed of automobile chassis, hydraulic lifting mechanism, cargo compartment and power take-off device. The carriage of a dump truck is divided into two types: backward tipping and sideways tipping. The movement of the piston rod is controlled by the control system. Rearward tipping is more common. Pushing the piston rod causes the carriage to tip over. A few tip over in both directions.
The two common types of dump trucks are 6*4 and 8*4. Commonly used for: urban dumping, engineering construction, land infrastructure, mineral transportation.
Because the loading compartment can automatically tip over to unload at a certain angle, it greatly saves unloading time and labor, shortens the transportation cycle, improves production efficiency, and reduces transportation costs. It is a commonly used special vehicle for transportation.
Dimension | 10800*2550*3450mm | |
Box size | 8500*2300*1700mm | |
Warranty | 12 months | |
Axle | Double rear axles (drum) | |
Motor | WECHAI 400HP Euro II | |
Transmission | HW19710 Heavy Duty with HW50PTO, 10-speed gearbox, 2 reverse gears | |
Frame | Double layers beam | |
Tyres | 16 pc, 12.00R20, 2040/1850/1850 | |
Wheelbase | 1950+3825+1350mm | |
Suspension | front 1540, rear 1635 (mm) | |
Departure corner | front 30, rear 27 | |
Leaf spring | Front 9, rear 10 | |
ABS & A/C | None | |
Bottom and side plate | Q235 material, bottom thickness 8 mm and side thickness 6 mm | |
Sleeper | Have one. | |
Braking System | Air brake, dump | |
Fuel tank | 300L | |
Toolbox | Have | |
PTO | HW50 | |
Hydraulic cylinder | Front-top/rear discharge type | |
Our production workshop is a professional, efficient and safe production place dedicated to providing customers with high quality products and services.
The workshop is equipped with advanced production equipment, a professional technical team and a strict quality management system to ensure that every production task is completed on time and in good quality.
Q1. What's your MOQ?
One unit trailer or truck.
Totally acceptable as you wish.
