1. Single / tandem axle vacuum trucks (water or vacuum trucks) are designed to fit on an under 10ton GVW chassis.
2. Tanks are built using high strength steel with dished and flange tank heads.
3. Our finish process includes both inside and outside epoxy coatings. Epoxy interior paint inside the tank will extend the life of your investment.
4. Exterior baked on enamel, including metallic and base-coat clear cote options will ensure that your truck image will match the quality of the work you do.
Chassis configuration:
Sinotruk Howo HW76 wide one and half row cabin, 4325+1350mm wheelbase
371HP diesel engine,
Howo 10-speed gearbox, 10 forward,2 reverse, manual operated
7 tons front axle and 16 tons double rear axle, 12.00R20 tubeless tires
Upper body configuration:
16 cubic meters tank volume, and it is made of 6mm high-quality carbon steel,
Equipped with hand-washing device, thick sewage observation pipe.
Using high quality vacuum pump, water-oil separator, an anti-overflow valve,
7m manure suction pipe, safety strut, and the rear door is hydraulically opened and closed.
Product descriptions:
| Complete Vehicle Parameter | |
| Vehicle | HOWO sewage suction truck |
| Overall dimension (mm) | 9470*2360*3160 |
| Sewage tank (m3) | 16m3 septic tanker truck |
| Gross vehicle weight (kg) | Appro×25000 |
| Curb weight (kg) | Appro×10000 |
| Payload (kg) | Appro×15000 |
| Wheel base (mm) | 4325+1350 |
| Max speed (km/h) | 90 |
| Chassis Parameter | |
| Cabin | Flat top cabin,a sleeper,power steering, air conditioner, 3 passengers,left hand drive,with Air Conditioner |
| Drive form | 6X4 |
| Engine | Brand: SINOTRUCK |
| Model: WD615.47,371HP | |
| Type: diesel, turbocharged, 6 cylinder. | |
| Displacement: 9726ml | |
| Emission standard: Euro 2 | |
| Transmission | 10 forward,2 reverse, manual operated |
| Tire model | 12.00R20 |
| No.of tires | 10 pcs, with 1pc spare tire |
| Superstructure Parameter | |
| Characteristic | 1. Sewage tank volume 16000liters Septic tanker truck |
| 2. Sewage tank material is carbon steel,thickness 5mm. | |
| 3. Sewage suction pipe 1pcs, length 7m. | |
| 4. Hydraulic lifting sewage tank,rear cover can open. | |
| 5. Equipped with PTO. | |
| 6. Equipped with vacuum pump. | |
| 7. Equipped with oil water separator, overflow valve,looking sewage window, self flow exit,hand washing device. | |
| Performance | (1) Vertical suction ≥ 7m. |
| (2) Pumping speed : 45L/s. | |
| (3) Intake and exhaust diameter: 50mm. | |
| (4) Full tank pumping time ≤ 5min. | |
| (5) Sewage tank emptying time ≤ 4min. | |
Sewage suction truck is a tank truck with a heavy duty vacuum designed to pneumatically load fecal, solids, liquids, sludge, crude oil or slurry through suction lines in diameter with 3" being the norm. We provide various sizes of sewage suction trucks with capacities ranging from 2cbm to 25cbm.
High-quality sewage suction pump with compact structure, uniform air flow, low noise, high vacuum. It can realize self-priming and self-discharging functions.
The electronic control operation in the cab and the whole vehicle control system can realize joint operation.
Company information
Successful cases
Overseas exhibition
Spare Parts
1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.
