CLW 4*2 I Suzu 7cbm 8m3 9000L 10000Liter 12000liters Garbage Compacted Compressed Compactor Truck
Product Description
1. Making garbage collection simple: change the dirty appearance of the city and eliminate the secondary pollution;
2. High compression ratio and large loading capacity which is 2 times larger than usual garbage truck;
3. Easy Full Automatic Operation: electrical control system for loading and unloading operations.
4. One Person Operation: Reducing sanitation work, greatly improves the working efficiency.
5. Double Operation System: electrical control system and manual operation greatly improves the vehicle usage rate.
Product Specification
| cabin | Driving type 4x2 | ||
| with A/C. Left Hand Drive. | |||
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 6800(7850)x1960x2600 | |
| Wheel base (mm) | 3360mm-4500mm | ||
| Wheel track (front/rear) (mm) | 1504/1425 | ||
| Approach/Departure angle(°) | 24/16 | ||
| Weight in KGS | Tare Weight | 5050 | |
| Front axles loading capacity | 2580 | ||
| Rear axles loading capacity | 4720 | ||
| Max. driving speed(km/h) | 90 | ||
| Engine | Brand | Japanese brand | |
| Model | 4KH1-TCG51 | ||
| Type | 4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||
| Horse Power(HP) | 120 HP | ||
| Emission standard | Euro V | ||
| Gearbox | 5 forwards &1 reverse | ||
| Clutch | Diaphragm spring clutch | ||
| Steering Gear | Power steering | ||
| Tire | 7.00R16 All radial tires with one spare, 7 pieces | ||
| Compression garbage box body system | |||
| BodyVolume | 7-12m3 | ||
| Cycle Time of Filling(S) | ≤40 | ||
| Lifting Time of Filler(S) | 8 to 10s | ||
| Time of Discharging | ≤60 | ||
| Working Pressure(MPA) | 16 | ||
| Composed by hermetic garbage tank, hydraulic system, operation system. The entire truck is hermetic, can automatically compress and dump the garbage .and the sewage generated in the process of the compression all go into the sewage tank. | |||
