CLW5696
Yes
1 Year
ISO9000, CCC, TS16949, CE
Euro 3, Euro 4, Euro 5
8t-12t
Manual
Diesel
10000-12000L
4x2
190HP
New
Diesel
Right Hand Drive & Left Hand Drive
8 Forwards & 1 Reverse
6mm Carbon Steel
Chinese Brand, Italy Brand or Other Imported Brand
8m
<5min
>8m
Customized
30 Days
ISO CCC SGS BV
3m3, 4m3, 5m3, 6m3, 8m3, 10m3, 12m3, etc.
Dongfeng, HOWO, FAW, Foton, JAC, etc.
6 Tires with One Spare
CLW
Naked, RO-RO, Bulk
7260*2500*3350mm
Suizhou, China
87059099
Product Description
Dongfeng Furuicar 4000Liters water tank 7000Liters Septic tank Vacuum sewage suction truck drainage tank truck
Description:
1. Drive type: 4x2, 4x4, 6x4, 8x4 etc.
Our factory has good business relationship with DONGFENG, FOTON, FAW, SINOTRUCK, SHACMAN, JAC, JMC, etc.
2. Tanker body: From 2m3 to 25 m3 capacity.
3. Accessory of sewage suction factions: Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.
Specification
Reference photos
Parts diagram
Working Diagram:
Factory overview
The CLW group, which was appointed by the Development and Reform Committee of China. CLW group is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.
Products Catalog:
1. LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor head
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Heavy duty wrecker tow truck/flatbed towing truck
16. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer manual, video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.
Spare Parts
1. Supplying quick-wearing parts at the truck delivery.
2. Good quality parts produced by the truck manufacturing factory.
3. Only charge cost price for customer convenience.
Shipment
Land transportation or Ship by bulk cargo ship, container, roro ship
After Sales Service
Email & Phone call tracking for each truck on timely manners.
Description:
1. Drive type: 4x2, 4x4, 6x4, 8x4 etc.
Our factory has good business relationship with DONGFENG, FOTON, FAW, SINOTRUCK, SHACMAN, JAC, JMC, etc.
2. Tanker body: From 2m3 to 25 m3 capacity.
3. Accessory of sewage suction factions: Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.
Specification
| Cabin | Driving type 4x2, single row | |
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm | 6820×2500×3350 |
| Wheel base (mm) | 3800 | |
| Wheel track (front/rear) (mm) | 1750/1650 | |
| Approach/Departure angle(°) | 23/20 | |
| Weight in KGS | Tare Weight | 7105 |
| payload | 8700 | |
| Front axles loading capacity | 4600 | |
| Rear axles loading capacity | 6500 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Brand | Cummins |
| Horse Power(HP) | 190HP | |
| Emission standard | Euro IV | |
| Gearbox | 8 forwards & 1 reverse | |
| Steering | Left hand drive | |
| Tire | 8.25R20, 6 tires with one spare | |
| Sewage Tank | ||
| Tank volume | Sewage tank 7000Liters | |
| Water tank 4000Liters | ||
| Tank material | 6mm carbon steel Q235 | |
| Tank size | 5000x1800mm | |
| Vacuum Pump | Chinese Vacuum Pump or Italy Vacuum Pump Model SK-12 | |
| High pressure cleaning pump | Flow speed: 215L/min | |
| Sewage suction pipe | 8M | |
| Main Performance | Suction time ≤ 5min, effective suction range ≥ 8m | |
| Other equipment | Oil-gas separator, water-gas separator, four-way valve, anti-flow valve, washing device, pressure gauge, ball valve | |
| Painting | Customized painting color and logo as required. | |
