Customized Garbage Compactor Truck Container Bin Body for Rubbish Collection
Product Description:
Garbage Compactor Body is a high efficiency to collect, compact, compresse and discharge solid waste, refuse ranging from ordinary to large refuses. Compactor is ideally suited for door to door collection and refuse is also collected at fixed points in containers. Garbage Compactor Body can be mounted on chassis configuration 4x4, 4x2, 6x4, 6x6, etc.
Specifications:
Compactor Body | Body dimensions(mm) | 4170×1730×1330 |
Volume | 5M3 | |
Body Floor steel | 5mm manganese steel | |
Body Roof steel | 4.5mm manganese steel | |
Body Side Plate steel | 4.5mm manganese steel | |
Ejection Plate steel | Ejection Plate steel | |
Hydraulic valve | Imported Japan | |
Water Tank | Volume | 150-600L |
Material | Stainless steel | |
Hopper | Volume | 1M3 |
Hopper Loading Height | 920mm | |
Side Plate steel | 5mm | |
Floor Plate steel | 5+3mm | |
Press Plate steel | 3& 5mm | |
Safety | 2 Pcs safety bars for hopper | |
Working Specification | Control mode | Automatic +Manual |
Compaction ratio | 1:3 | |
Time for single loading cycle | 10-11s | |
Time for single discharge cycle | <18s | |
Max broke force of compression | 16T |
Truck Diagram:
Details:
Truck Details:
The CLW group, which was appointed by the Development and Reform Committee of China. CLW group is a professional company who deal in different kinds of special vehicles, trailers and construction machinery.
