CLW5100WTC
LED Advertising Truck
Outdoor Activity
3.5L
Operating System
3
Diesel Oil
SMD
Self-powered
Own Generator-powered
4.0mm; 5.0mm; 6.0mm
4X2/6 Wheels/4*2
3300mm; 3306mm; 3360mm; 3400mm
6m2; 6.5m2; 7m2; as Per Chassis Size
Full Color and Monochrome
8kw; 10kw; 12kw; 15kw; 18kw; 20kw
Diesel/Gasoline
China Local Brand
40W; 60W; 80W; 100W
Optional
China Local Brand
Optional; 2 PCS or 4 Pics
China Local Brand; 2 PCS
Optional; 4.4m2 or as Per Customer
120W; 240W; 360W; 420W
CLW
Naked with Wax
Small Size
Suizhou, China
870509990
Product Description
Product Description
1. Purpose: For mobile advertising, products promotion, branding, concerts and so on. It can on-site display, exchange, interaction, wide publicity and gain great effective of advertising.
2. Main parts: LED screen, Generator set, Computer, Control system etc.
3. Optional items: Mobile stage, Scrolling light box.
4. LED screen: SMD P4 P5 P6 P8 for optional.
5. Generator brand: China famous brand and Internation brand for optional
Specification
| Condition | New condition/LHD/RHD/4x2 | ||
| Chassis | Brand | SINOTRUK | |
| Model | HOWO | ||
| Curb weight(kg) | 4300 kg | ||
| Front/Rear Axle loading(kg) | 2000/3500 kg | ||
| Wheelbase(mm) | 3360 mm | ||
| Dimensions(mm) | 5995*2030*3050 mm | ||
| Front/Rear overhang(mm) | 1160/1475 mm | ||
| Wheel track (front/rear) (mm) | 1605/1520 mm | ||
| Approach/Departure angle(°) | 20/19 ° | ||
| Max. driving speed(km/h) | 90 km/h | ||
| Clutch | Reinforced diaphragm clutch | ||
| Brakes | Service brake: dual circuit compressed air brake. Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels. Auxiliary brake: engine exhaust valve brake | ||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 6pcs with one spare tire | |
| Specifications | 6.50R16 nylon tire | ||
| Transmission | Manual type, 5 Forwards and 1 reverse | ||
| Cab | It can accommodate three people. With Air conditioner. With Air deflector(Air curtain) | ||
| Engine | Model | 4DW93-84NG2 | |
| Fuel type | Diesel | ||
| Displacement(ml) | 2540 ml | ||
| Power(kw) | 64 kw | ||
| Horsepower(HP) | 85 HP | ||
| Cylinder number(pcs) | 4 pcs | ||
| Emission standard | Euro 2 | ||
| LED Advertising Screen System | |||
| Upper | 1. One side P6 LED outdoor full color display screen, customized size. 2. One unit mobile stage 3. Silent diesel generator set 4. Control system,sound system 5. Amplifier 1pc, Control Panel 1pc. 6. Waterproof wood floor | ||
