Sdcy100K9h1-T Lift Truck 10 Ton 9 Layer Empty Container Handler

Product description

Model	SDCY100K9C1-T
Overall weight	42 t
Max. loading capacity	10 t
Layer of stack	9(8'6")
Max. hoisting speed (Non-load/Load)	450/350 mm/s
Max. Descending speed (Non-load/Load)	500/500 mm/s
Overall dimension	7610*6620(12750)*12315(22037) mm
Engine	VOLVO TAD851VE
Rated power	185/2200 kW/rpm
Gearbox	DANA 340TE17000
Drive Axle	KESSLER D81 PL488

1. Dynamic Anti-Rollover Protection Technology
Adopt intelligent control technology, detect equipment' s real-time working parameters and automatically adjust the operating status under dangerous conditions to prevent rollover. It can achieve safe and worry-free operation.
2. Extra High Mast Design Technology
F-type mast is creatively developed to reduce shaking. It is curve and twist resisting and highly rigid, safe and reliable.
3. Patented Mast Clamping Alarm Technology
An intelligent monitoring device will detect the blocking and send alarm. The main electronic control system can lock the dangerous operations to prevent further damage, comprehensively eliminate safety hazards.
4. Spreader Horizontal Slew Patent Technology
Aligning and lifting container more conveniently and quickly. It greatly decreases the friction between tyre and floor, reduces fuel consumption and saves costs.
5. Efficient Control Technology
The centralized joystick has inching control function. It can realize fine tuning to millimeter precision easily. All the spreaders' motions are under proportional control, providing an experience of man-machine unification. The machine also has multi-motion linkage design so that it can operate faster and more efficiently.
6. Hurdling Twin Container Spreader
Hurdling and twin container spreaders are developed to meet customers' needs. It can vertically rotate ±4°to improve alignment efficiency.
