MFP-7 Series
Wall-Mounted Type
Resistive
Contact
Analog Type
Ceramics
Ceramics
Temperature
IP65
RoHS
Customized
-40 to +105 Degrees
Focusens
Natural Export Packing
fast response
Hefei, Anhui, China
9025900090
Product Description
Specifications:
Sensor: NTC thermistor R25(25°C): 10KΩ
Accuracy: ±1%, ±2%, 3%
B value: R25/50:3435K
Long term stability (1 year): ±0.1%
Working temperature range: -40~~105 Celsius degrees
Lead wire: PVC wire
Other Options:
Features:
1. Fast response,
2. High temperature,
3. measuring precision,
4. Small volume,
5. convenient installation,
6. Heat resistant plastic shell,
7. High reliability and long term stability.
Typical Applications:
Pipe heating
Floor heating
Cogeneration systems
Other Products:
Contact Us:
Focus Sensing and Control Technology Co.,LTD
Sales Manager
Cherry Chen
Tel: +86-551-69109668
Sensor: NTC thermistor R25(25°C): 10KΩ
Accuracy: ±1%, ±2%, 3%
B value: R25/50:3435K
Long term stability (1 year): ±0.1%
Working temperature range: -40~~105 Celsius degrees
Lead wire: PVC wire
Other Options:
| Sensor Type | NTC: 5K, 10K, 20K, 50K, 100K, customized |
| Operatating Temperature Range | -20~120 C, -30~250 C,-40~350 C, or customized |
| Resistance Tolerance | 0.5%, 1%, 2%, 3%, 5% |
| Housing | Nickel plated copper, brass, stainless steel, aluminum, or customized Size is customized |
| Wire | Teflon wire, PVC wire, Silicone wire, customized; Length is customized |
| connector | As required |
| Special Request | Waterproof, anticorrosion, or other |
Features:
1. Fast response,
2. High temperature,
3. measuring precision,
4. Small volume,
5. convenient installation,
6. Heat resistant plastic shell,
7. High reliability and long term stability.
Typical Applications:
Pipe heating
Floor heating
Cogeneration systems
