The STS3x is high-accuracy digital temperature sensor series. The STS3x temperature sensor utilizes the industry-proven technology and wins over users with its increased intelligence, reliability, NIST traceability and improved accuracy specifications. There are also automotive grade versions available.
The STS3x temperature sensor gives a fully calibrated, linearized, and supply-voltage-compensated digital output and has an outstanding accuracy of up to +/-0.1°C. There are three versions available: the standard version, STS31, guarantees an accuracy of ±0.2°C over a temperature range of 0°C to 90°C, while the low-cost version, STS30, has an temperature range of 0°C to 65°C. The high-end version STS35 is the most accurate temperature sensor available with an accuracy of ±0.1°C over a temperature range of 20 to 60°C.
STS3x series including: STS30/ STS30A/ STS31/ STS31A/ STS35
Features
· Output: I²C
· Energy consumption: 5.6 µW (at 3.3 V, low repeatability, 1 measurement / s)
· Temperature operating range: -40 to +125°C (-40 to +257°F)
· Temperature response time: 2 sec (tau63%)
· Accuracy tolerance: Up to ±0.1 °C
| Item | Condition | Specification |
| STS30 Accuracy Tolerance | Typ., 0ºC to 65ºC | ±0.2ºC |
| Max. | ±0.4ºC | |
| STS31 Accuracy Tolerance | Typ., 0ºC to 90ºC | ±0.2ºC |
| Max. | ±0.4ºC | |
| STS35 Accuracy Tolerance | Typ., 20ºC to 60ºC | ±0.1ºC |
| Max. | ±0.3ºC | |
| Repeatability | Low | 0.15ºC |
| Medium | 0.08ºC | |
| High | 0.04ºC | |
| Resolution | Typ. | 0.01ºC |
| Specified Range | - | -40 ~ +125ºC |
| Response time | τ63% | >2s |
| Long Term Drift | Max. | <0.03ºC/Yr |
Focusens are Chinese Sensor Expert that have more than 15 years manufacturing experience. We are committed to provide high quality thermal Components NTC thermistors, PTC thermistors, NTC sensors, PT100 PT1000 RTD sensors ,thermocouples, silicon liner PTC sensors as well as digital sensors.
Our activities covers all over the world. Key players like Samsung as well as Chinese manufacturers like Galanz, Medtronic, Mindray, BYD etc. are among our clients list.
Flexible custom design and prompt delivery are our always advantages. Meanwhile we accept OEM on customers design.
Contact us now for details and improve projects efficiency with our expertise!
All parameters can be customized. Please see below information for your reference, tell us your detailed requirements.
Part A: Sensing Elements
| Item | Specification |
| Thermistor | NTC, PTC |
| RTD series | PT10, PT20, PT100, PT200, PT500, PT1000 |
| Digital series | DS18B20, STS35, TMP117 etc. |
| Analog series | LM35 |
Part B: Housings
Part C: Wires
| Item | Specification |
| AWG | 18, 20, 22, 24, 28 etc. |
| Material | PVC, Silicone, Fiberglass |
| Outer diameter | 2.5mm, 3.0mm, 3.2mm, 4.0mm, 5.0mm, 6.0mm |
Part D: Connectors
What Focusens can provide you:
1. How can I get samples?
Discuss to one of our sales, tell him or her your requirements. After confirmed details, we will arrange samples production. Customer need to pay for shipping cost. (Check with sales whether your samples can be free)
Normally it takes 15-30 days to produce samples.
4. Do you accept customized?
Yes, we accept ODM&OEM. Products can be customised upon customer's requirements.
5. How long is your lead time?
Generally, 2-3 weeks for regular products. Sometimes, it needs more time to prepare materials and do more tests to ensure products' accuracy.
Welcome to contact us for much more details!
