490b-03014 3015
Online Service
Online Service
Standard
Camshaft
Original
Standard Export Package
Xinchai
Wooden Box
15x30x30cm
China
8409999100
Product Description
| NO. | Part no. | Part name | NO. | Part no. | Part name |
| 1 | GB/T5782-2000 | Bolt M8x30 | 1 | 490B-31203 | Pin |
| 2 | GB/T859-1987 | Washer 8 | 2 | 490B-31001 | Oil pump driving gear |
| 3 | GB/T849-1987 | Washer 8 | 3 | 490B-31004 | Oil pumnp housing |
| 4 | GB/T5782-2000 | Bolt M8x25 | 4 | GB/T97·1-2002 | Washer 8 |
| 5 | GB1192-2000 | Pin B8x20 | 5 | GB/T93-1987 | Spring washer 8 |
| 6 | GB/T5782-2000 | Bolt M8x70 | 6 | GB/T5785-2000 | Bolt M8 x30 |
| 7 | 490BPG-160001 | Cover | 7 | GB/T5783-2000 | Bolt M8 x20 |
| 8 | 490BPG-160002 | Casket | 8 | 490B-33000 | Piping assembly |
| 9 | 490BPG-82014 | Adjusting screw | 9 | 490B-33005 | Gasket |
| 10 | GB/T6171-2000 | Nut M8x1 | 10 | GB/T6170-2000 | Nut M8 |
| 11 | 490BPG-82008 | Bearing cover | 11 | GB/T5782-2000 | Stud M8 |
| 12 | 490BPG-82009 | Gasket | 12 | 490B-31100A | Screen filter |
| 13 | 490BPG-82001 | End plate | 13 | 490B-31006 | Oil filter gasket |
| 14 | GB/T297-1994 | Bearing 30207 | 14 | 490B-31005 | Cover,oil pump |
| 15 | GB/T5782-2000 | Bolt M8x20 | 15 | GB/T308-1989 | Steel ball 10 |
| 16 | GB/T5782-2000 | Bolt M8x40 | 16 | 490B-31003 | Spring |
| 17 | 490BPG-82003 | Washer | 17 | 490B-31002 | Screw |
| 18 | GB/T5782-2000 | Bolt M8x60 | 18 | GB/T6171-2000 | Nut M14x1.5 |
| 19 | GB/T5782-2000 | Bolt M8x15 | 19 | GB/T6173-2000 | Nut M14x1.5 |
| 20 | 490BPG-02100 | Oil pipe | 20 | 490B-31007 | Cover,oil pump gasket |
| 21 | 490B-02012-1 | End plate | 21 | 490B-31202 | Inner rotor |
| 22 | 490BPG-82007 | Hydraulic pump gear | 22 | 490B-31008 | Outer rotor |
| 23 | GB/T5782-2000 | Bolt M8x50 | 23 | 490B-31201 | shaft of oil pump |
| 24 | 490BPG-82006 | Snap plate | 1 | GB/T5782-2000 | Bolt M8x70 |
| 25 | 490BPG-82004 | Bridge gear | 2 | GB/T93-1987 | Spring washer 8 |
| 26 | GB/T276-1994 | Bearing 6009 | 3 | 490B-41100-1 | Fan |
| 27 | GB/T893·1-1986 | Snap ring 75 | 4 | 490B-41003-3 | Gasket |
| 28 | 490BPG-82005 | Gear shaft | 5 | 490B-41002 | Fan pulley |
| 29 | 490BPG-82010 | Gasket | 6 | 490B-41001 | Fan belt |
| 30 | 490BPG-82011 | Connecting plate | 7 | GB/T6178-2000 | Nut M10 |
| 31 | 490BPG-82012 | Gasket | 8 | GB/T93-1987 | Spring washer 10 |
| 32 | 490BPG-82013 | End cover | 9 | GB/T97:1-2002 | Washer l0 |
| 33 | GB21-76 | Bolt M10x45 | 10 | 490B-42001 | Fan pulley hub |
| 34 | GB/T859-1987 | Washer 10 | 11 | 490B-42011 | Snap ring 40 |
| 35 | GB/T849-1987 | Washer 10 | 12 | GB/I278-1989 | Bearing |
| 36 | 490BPG-02003 | Pump timing gear | 13 | 490B-42003 | Sleeve spacer |
| 37 | 490BPG-02006 | Timing idlc gear | 14 | GB/T1099-1979 | Key 5x19 |
| 38 | 490B-02005 | Bushing | 15 | 490B-42002 | Water pump shaft |
| 39 | 490B-02004 | Idle gear shaft | 16 | GB/T5782-2000 | Bolt M8x70 |
| 40 | 490BPG-82002 | Screw | 17 | GB/T97:1-2002 | Washer 8 |
| 41 | GB/T5782-2000 | Bolt M12x45 | 18 | 490B-42004 | Water pump housing |
| 42 | GB/T859-1987 | Spring washer 12 | 19 | GB1152-1989 | Oil cup |
| 43 | 490B-02011 | End cover | 20 | 490B-42005 | Gasket |
| 44 | 490BPG-02009 | Camshaft timing gear | 21 | GB/T5782-2000 | Bolt M8 x50 |
| 45 | GB/T1096-1979 | Key C12x63 | 22 | 490B-42011 | Gasket |
| 46 | 490BPG-02007 | Crankshaft timing gear | 23 | 490B-42006 | Back plate |
| 47 | GB/T5782-2000 | Bolt M8x45 | 24 | 490B-42008 | Water pump impeller |
| 48 | 490BPG-16003 | Timing gear housing | 25 | 490B-42009 | Water seal |
| 49 | 490BPG-16009-1 | Gasket | 1 | 490B-16011-1 | Gasket |
| 50 | GB/T5782-2000 | Bolt M8 x75 | 2 | 490B-21000 | Fuel injection pump |
| 51 | 490B-16008 | Gaskct | 3 | GB/T29·1-1988 | Bolt M6x25 |
| 52 | 490B-16004-1 | Connecting flange | 4 | 490B-23501 | Clamp |
| 53 | 495B-02105 | Axle sleeve | 5 | 490B-23502 | Rubber gasket |
| NO. | Part no. | Part name | 6 | GB/T93-1987 | Spring washer 6 |
| 1 | A498B-11002 | Rubber pad | 7 | GB/T6172-2000 | Nut M6 |
| 2 | A498B-11001-2 | Cylinder head cover | 8 | A490B-22000 | Fuel injector |
| 3 | 490B-11013B | Cap gasket | 9 | A490B-25100-1 | Injector leak-off pipe |
| 4 | A498B-11003 | Rubber isolation bushing | 10 | A490B-23101 | 1st cylinder high pressure fuel tube |
| 5 | A498B-11004 | Washer | 11 | A490B-23201 | 2nd cylinder highpressure fuel tube |
| 6 | C490BPG-11009-2 | Nameplate | 12 | A490B-23301 | 3rd cylinder highpressure fuel tube |
| 7 | GB/T827-1986 | Rivet 2x5 | 13 | A490B-23401 | 4th cylinder highpressure fuel tube |
| 8 | GB/T923-1988 | Nut M8 | 14 | 490B-25200 | Fuel supply tube from fuel filter to injection pump |
| 1 | 490B-32000B | Oil filter | 15 | 490B-24000A | Fuel fulter |
| 2 | 490B-53001-4 | Adjusting lever for generator | 16 | GB/T97·1-2002 | Washer 8 |
| 3 | GB/T97·1-2002 | Washer 8 | 17 | GB/T93-1987 | Spring washer 8 |
| 4 | GB/T93-1987 | Spring washer 8 | 18 | GB/T5783-2000 | Bolt M8 x30 |
| 5 | GB/T5783-2000 | Bolt M8 x 25 | 19 | 490B-25300 | Fuel supply tube from supply pump to fuel filter |
| 6 | 490B-51000 | Starting motor | 20 | 490B-25401-4 | Fuel supply pump connector |
| 7 | GB/T5782-2000 | Bolt M10 x 80 | 21 | 490B-25401-4 | Sebific duct |
| 8 | 490B-52000 | Charging generator | 22 | 498B-25001 | Leakproof cap |
| 9 | GB/T97·1-2002 | Washer 10 | 23 | 498B-25004 | Clamp |
| 10 | GB/T93-1987 | Spring washer 10 | 24 | JB/T982-1977 | Springle Washer |
| 11 | GB/T6170-2000 | Nut 10 |
Company Profile
Jinan Gem Auto Parts Co ltd do chinese truck parts market for many years, we supply Heli, Hangcha, Jac forklift , forklift engine assy and engine parts. Also we supply sinotruk, shacman truck, weichai engine parts.FAST FC gearbox spare parts.we also the agent for shanxi fast gear copany. original parts with best price. we have manufactry ,can make as customer requirement.such as quality and custormized.
Our company was founed in 2017 for importation,but have more than 20 years experience on domestic mining truck,construction machine and chinese truck spare parts selling. specialized in various types of heavy trucks. is one of the leading manufacture, wholesaler, trader and exporter of diesel engine spare parts, trasmission gearbox spare parts mining truck spare parts transit mixer spare parts, deutz engine parts, crane spare parts and road roller spare parts components and assemblies for automotive application. with our sincere efforts, we have been able to carve a niche for ourselves in this domain.
What We Have :
Oem Spare Parts No System--You Can Only Show Us Engine Namepalte Or Chassis No,We Will Response You Exactly Part No , Specification And Size.
What Quality We Have :
We Are Engent Of Weichai And Fast Gearbox Original Spare Parts, Original ,Oem ,Customized Quality Copy Abc.
What Our Package:
Wooden Box With Plastic,Paper Box ,Carton, Pallet With Plastic
What Our Payment:
Lc And Tt ,and Wester Union and Installment. Long Time Honest Distribution Give Credits
What We Will Do:
We Will Honest To Each Customers Of Quality And Give Best Suggestion
What We Have In Stock:
Fast Moving Items ,Such As Filter , Fan Belt ,Body Spare Parts ,Sensor Valve Has In Stock For Container Bulk Order ,We Need To Take Arround 10-30 Working Days
What Our Exporting Port :
FOB Qingdao port (Any Chinese port),Door to door to your warehouse,CIP,CIFand EXW
Why Our Price Has Advantage:
We Are In Jinan City Where Is Biggest Spare Parts Distribution City In China And Spare Parts Manufacture Center !!!!!
Why Choose Us:
a) focused on chinese brand vehicle parts with 20 years'professional experiences,we have exported over 50 countries in Africa, Middle East, Southeast Asia, and South America. Our overseas authorized truck dealers and service dealers are all around the world.
b) auto parts exporter agent for many factory
c) professional work team with excellent service & fast response in 24 hours
d) 100% accept if any claim happen as reasonable
e) honor and honesty agreement with full of competitor prices
f) excellent package with label for each part & wooden package as required
Deliver Goods
