ZA14J/ZA18J
Spare Parts Free
One Year Warranty
Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Articulated Lift
Middle-Level
Self-propelled
AC
Stationary
Explosion-Proof, Insulating
GS, CE, RoHS, ISO 9001
15.8m
20.93m
300kg
250kg
Zoomlion
Standard Package for Shipment
ISO
Hnan, China
Product Description
Chinese Famous Brand Zoomlion Aerial Working Platform ZA14J/ZA18J Articulating Boom Lift
Features:
Horn All motion alarm Proportional control Self-closing entry gate Flashing amber beacon Auto-leveling system Emergency stop button Over tilt protection system Emergency descent system On-board diagnostic system Oscillating axle 4.3' LED display Load sensing system Swing-out engine tray
Parameters:
Main Specs of Articulating BoomLifts | |
Comply with CE/ANSI/GB Standard | |
Model | ZA14J |
Size | |
Work Height | 15.80m |
Platform Height | 13.80m |
Horizontal Outreach | 7.70m |
Up and Over Height | 7.55m |
A - Stowed Length | 6.57m |
B - Stowed Width | 2.30m |
C - Stowed Height | 2.27m |
D - Platform Length | 1.83m |
E - Platform Width | 0.76m |
F - Wheelbase | 2.36m |
G - Ground Clearance | 0.42m |
Performance | |
Platform Capacity | 300kg |
Speed | 6.8km/h |
Gradeability | 45% (24°) |
Axles Oscillation | 0.1m |
Turning Radius (Inside) | 2.06m |
Turning Radius (Outside) | 4.78m |
Swing | 355° |
Platform Rotation | ±90° |
H-Tail Swing | 0 |
Max. Working Slope | 5° |
Max. Wind Speed | 12.5m/s |
Power | |
Diesel Engine | Dutz D2.9L4 |
Engine Power | 35.7kw/2600rpm |
Fuel Tank Capacity | 65L |
Auxiliary Power | 12V |
Control Voltage | 12V |
Hydraulic System Capacity | 150L |
Hydraulic Tank Capacity | 76L |
Tire | |
Type | 315/55 D20 Foam-filled Tires |
Weight | |
Gross | 7100kg |
Highlights | |
300 kg platform capacity for higher efficiency | |
Built-in multiple pressure control leveling system to enhance stability | |
Precise load sensing system to improve overload safety operations | |
Integrated with rotary reducer to enhance rotation stability | |
Hostile Kits available for dusty working environment | |
Deadweight Lowering System for smooth operation and energy efficiency | |
