EBZ135 machine is mainly used for rocks with hardness ≤7, including coal roadway, semi-coal roadway and soft rock roadway and tunnel driving.And it can achieve continuous cutting,loading, transport operations.The maximum positioning cut surface can reach 20.5 square meters, climbing ability is plus-minus (±) 18°
Main Technical Specification
EBZ135
Cutting Motor Power
135Kw
Oil Pump Motor Power
75Kw
Cutting Hardness
≤70MPa
Location Cutting Range
Height: 4 m
Width: 5.1 m
Machine Weight
38.8 T
Dimension (Length * Width * Height )
8.92*2.8*1.53 m
Rotary speed of cutter head
44 r/min
Rotary Speed of star wheel
33 r/min
Loading capacity
3.4 m³/min
Speed of 1st conveyor
40 m/min
Grade Ability
±18º
Gantry Height
400 mm
Hydraulic System Pressure
≤18 MPa
Hydraulic Oil Tank Capacity
500 L
Dinting Depth
0.2m
Supply Voltage
AC1140/660V
