SR175-S
Online Support
1year
CE, RoHS, ISO 9001:2000, ISO 9001:2008
New
>300mm
50-70m
Diamond Bit
Rotary
Crawler
1500mm
44/56
Cu -Mins 180kw
180kn
top brand
Nude Package
15112x3212x3560mm
China
Product Description
SR175-S China Brand High quality Energy saving Efficient Maximum Drilling Depth 56 m Rotary Drilling Rig
Strong power: the new national four engine, full fuel combustion, high efficiency; Advanced power control system, give full play to the performance of the pump valve, high efficiency of the actuator.Efficient construction: fast drilling and fast dumping during soil layer construction; During rock drilling, the torque is large, the pressure is large, the cutting efficiency is high, the comprehensive construction efficiency is high.
Strong adaptability: the performance of the whole machine is upgraded to adapt to complex strata; Far more than the same level of lifting power, can easily cope with large holes, deep holes, silt layer.
Stable and reliable: low center of gravity of chassis, high weight ratio, double rotation, lengthening off, rig construction is more stable: mast, amplitude and other mature box structure and further strengthened, market verification is full, strong and more durable; Full drilling depth single-layer winding design, wire rope life extended by 1 times.
Intelligent assistance: HD touch screen, integrated display, control, leisure functions in one, the interface is full of science and technology, simple operation; The intelligent drilling function can realize man-machine separation and reduce the manual operation intensity.
New feeling: intelligent cockpit, air conditioning cooling performance improved by 10%, reasonable air outlet position and seal design, always in a low noise constant temperature state; The right side glass area is increased by 30%, and the operating field is more open.
Convenient maintenance: large maintenance space; Double-side ladder, machine maintenance channel smooth; Optional automatic centralized lubrication system, saving time and effort.
| Item | Unit | SR375-S | SR175-S | |
| Basic parameter | Max. drilling diameter | mm | 2500 | 1500 |
| Max. drilling depth | m | 65/103 | 44/56 | |
| Engine | - | IS-UZU | Cum-mins | |
| Rated power | kW/rpm | 348/1800 | 180/2000 | |
| Rated output torque | kN*m | 375 | 175 | |
| Pressurized cylinder | Max. pressure | kN | 300 | 160 |
| Max. lifting force | kN | 340 | 180 | |
| Distance of travel | m | 6 | 4.2 | |
| Main hoisting | Maximum lifting force | kN | 380 | 170 |
| Maximum lifting speed | m/min | 75 | 80 | |
| Wire rope diameter | mm | 36 | 26 | |
| Auxiliary hoist | Maximum lifting force | kN | 105 | 60 |
| Maximum lifting speed | m/min | 80 | 60 | |
| Wire rope diameter | mm | 20 | 16 | |
| Drill mast inclination | Side/forward/backward | ° | ±4/5/90 | ±4/5/90 |
| Base plate | Base place width | mm | 4820 | 4100 |
| Track width | mm | 800 | 700 | |
| Machine | Working weight | t | 120 | 52 |
| Transport status | mm | 19540*3500*3700 | 14115*3100*3570 | |
