4079001300 4079001301 4079001302 Saf CV Brake Disc with Kits

Supplier Qingdao Pujie Industry Co., Ltd.
Price $31.28 / Pieces
Availability In Stock
Mini Order:
+-
Subtotal: $312.8

Purchase details

Payments:

Tax:

Tax Included

Returns&Refunds:

Eligible for refunds within 30 days of receiving products. returns and refunds

4079001303
Brake Pads
Semi-Metal
Front
ISO/TS16949, ISO9001
Full Metal, Semi Metal., Ceramic
Brake Pad
Eastern Europe
430mm
45mm
164mm
190mm
18 Months From Purchasing
More Than 10years
PUJIE
Standard and Customized Packing
standard
Shandong, China
8708301000
Product Description
1.  Description of brake disc : 4079001300


Cast iron
CHEMICAL COMPOSITION(mass%)
 CSIMnNiCrMoCuSPSnTiV
% MIN3.651.60.4/0.15/0.3/////
% MAX3.82.10.80.10.350.250.60.150.10.150.050.05
MICROSTRUCTURE
MATRIXType of matrixFine Lamellar
Permissible limit  5% Max, well distributed
LedebutiteNot permissible
GRAPHITE (To UNI EN ISO 945)Shape∣
Distribution A: 70% MIN
D·E:<4% Disporsed
B: Resto/Remainder
Size3- 4 -5 : 70% MIN
2: Traces
6:≤15%
Cementite and free carbidesTraces up pt 1% MAX permissible
MECHANICAL PROPERTIES OF CASTING
HARDNESS (HBW)On machined braking surfaces170~210
On braking surfaces as-cast (0.5 mm below surface)230MAX
TENSILE STRENGTH(Rm) (N/m²)On braking surface170 MIN
On mounting flange
WEDGE INDENTATION STRENGTH (Rmk)(N/m²)On braking surface125 MIN
Young's MODULUS (E) (N/m²)/95
PHYSICAL PROPERITIES  (Indicative values)
Density  (volumic mass)7.1 kg/dm³
Coefficient of thermal expansion at 20 degree 9.10 1/K
Thermal conductivity at 100 degree50 W/Mk

2. Foundry :
The foundry - At the heart of production
The quality and productivity of our plants are what optimally ensure 20 million cast parts can leave our factory each year.
The set of procedures for manufacturing brake discs are characterised by specialised and coordinated processes. Short transport routes, carefully tailored production stage capacities and flexibility all underpin our high productivity.

Automatic core production
6 Cool-box core production centres with automated core handling
High-rack core depot with a capacity of 20,000 cores
Fully automatic core transport to moulding plants
Moulding material preparation
Computer-controlled processing of clay-bonded moulding material
3 automatic vacuum mixers
Smelting
4 medium-frequency crucible furnaces
1 unlined water-cooled hot-blast cupola furnace
1 mains frequency channel-type induction furnaces
4 mains frequency crucible furnaces
The smelting output is currently 260,000 tonnes of molten iron per year, which Buderus Guss makes exclusively using steel scrap and returns.

Moulding and casting
 6 fully automated vertical moulding plants
 6 induction-heated casting furnaces
 Camera-controlled fully automatic casting stopper controls
 Laser-controlled casting stopper control

Raw casting finishing
Blasting and grinding in a through-feed process with four countinous rocker Barrel
Automatic visual inspection of brake discs with 4 triangular laser camera systems
Automatic robot-driven packaging of brake discs
3. Our catalogue:

APPLICATIONOE NO.
MERITOR23123547
 16823123647
NEOPLAN82135830
MERCEDES/SETRA8285390000
MAN81508030040
MAN81508030041
VOLVO85103803
VOLVO3092710
MERCEDES-BENZ9424212112
SCANIA1402272
SAF4079000700
IVECO2992477
IVECO2996328
RENAULT5010525014
MAN81508030042
MERCEDES-BENZ9704210112
RENAULT5010525308
IVECO2995702
RENAULT5010260218
DAF1400069
MERCEDES-BENZ9754210112
MERCEDES-BENZ9434210312
DAF OLD1387439
DAF NEW1387439
SAF4079001300
SAF4079001000
MERCEDES-BENZ3564211012
IVECO1906461
MERCEDES-BENZ9704230612
MERITOR21225115
MERITOR21225115
BPW308834060
MERCEDES-BENZ9754230612
MERCEDES-BENZ9704230512
MERCEDES-BENZ9704230212
BPW308834107
BPW308835050
BPW308835050
BPW0308835127
BPW0308834217
MERCEDES-BENZ6684230012
RENAULT5010422363
VOLVO85103804
VOLVO85103805
MERCEDES-BENZ6884210212
MERCEDES-BENZ6884230012
MAN81508030057
MERCEDES-BENZ6684230112
MERCEDES-BENZ6684230412
GAZ33104-3501078
VOLVO85103806
SCHMITZ CARGOBULL017870
SAF4079000500
SAF4079001700
SAF4079001800
BPW0308834137
VOLVO20995144
MERCEDES-BENZA6684230512
FORD6172906
MERCEDES-BENZ9064210012
DAF1400284
BPW308834040
MERCEDES-BENZ9064230112
VOLVO20700508
BPW308835030
MAN81508030014
MERITOR1489860
MERITOR68323825
BPW308835010
SMBM069018
MERCEDES-BENZ A6694210512
BPW308834080
MERCEDES-BENZ 6754210012
RENAULT5010598304
SAF4079001500
SCHMITZ CARGOBULL1088133
BPW0308834010
BPW0308834030
BPW0308834030
BPW0308834070
BPW0308835060
RENAULT5010216437
IVECO2996418
MITUBISHIMX925098
DAFPAK3545;MAK7429;MAK7529;RAK7404;PAK5513;AMPB889
DAFPAK3545;MAK7429;MAK7529;RAK7404;PAK5513;AMPB889
DAFPAK3545;MAK7429;MAK7529;RAK7404;PAK5513;AMPB889
DAFPAK3545;MAK7429;MAK7529;RAK7404;PAK5513;AMPB889
DAFPAK3545;MAK7429;MAK7529;RAK7404;PAK5513;AMPB889
IVECO7171255;1907765
IVECO7171255;1907765
MCWX1857658;X2057948
MCWX1857658;X2057948
VOLVO6774687;6774686
VOLVO6774687;6774686
RENAULT5000450158;5000545242
RENAULT5000450158;5000545242
RENAULT5010216548;5000792539
RENAULT5010216548;5000792539
MAN81508030022
MAN81508030026
VOLVO6775227;6775229;67752279;6775223
VOLVO6775227;6775229;67752279;6775223
VOLVO6775227;6775229;67752279;6775223
VOLVO6775227;6775229;67752279;6775223
SMBM069018
R.V.I./RENAULT5010260609
RENAULT5010260603
DENNIS655750
VOLVO20564467
LECINENA12001500002;12001500021;120015000188;3124004200
LECINENA12001500002;12001500021;120015000188;3124004200
LECINENA12001500002;12001500021;120015000188;3124004200
LECINENA12001500002;12001500021;120015000188;3124004200
RENAULT/VOLVO5010598305;20700509
RENAULT/VOLVO5010598305;20700509
LECINENA12001500005;3124021200
LECINENA12001500005;3124021200
SETRA1792411113070;4940065;8284000147;350103
SETRA1792411113070;4940065;8284000147;350103
SETRA1792411113070;4940065;8284000147;350103
SETRA1792411113070;4940065;8284000147;350103
SMBM078157;449418;103836
SMBM078157;449418;103836
SMBM078157;449418;103836
IVECO2992636;7184078;7184082
IVECO2992636;7184078;7184082
IVECO2992636;7184078;7184082
IVECO2995702;2995894;7187541;2996708
IVECO2995702;2995894;7187541;2996708
IVECO2995702;2995894;7187541;2996708
IVECO2995702;2995894;7187541;2996708
RENAULT5010525364
SAF4079000400;4079000401;1079000400
SAF4079000400;4079000401;1079000400
SAF4079000400;4079000401;1079000400
NISSAN40206D9200
DAF1403758;1408253;1408671
DAF1403758;1408253;1408671
DAF1403758;1408253;1408671
NISSAN402069X401
IVECO/VOLVO42471214
NISSAN40206MB600;5001871213;40206LC60A
NISSAN40206MB600;5001871213;40206LC60A
NISSAN40206MB600;5001871213;40206LC60A
NISSAN432079X100
NISSAN402069X403;40206MA50A;402069X404
NISSAN402069X403;40206MA50A;402069X404
NISSAN402069X403;40206MA50A;402069X404
RENAULT5010216932;5010260102
RENAULT5010216932;5010260102
RENAULT5010260218
BPW0308834130;0308834137
BPW0308834130;0308834137
MERCEDES6754210012
IVECO2994031
RENAULT5010598304;5513AA1549
RENAULT5010598304;5513AA1549
RENAULT5010525362;5010525015
RENAULT5010525362;5010525015
RENAULT5000790539
IVECO93161407
RENAULT5010216931;5010260101
RENAULT5010216931;5010260101
MERCEDES3564211212
MITSUBISHIMC894848
MITSUBISHIMK374048
HINO23123624007
HINO23123625002
HINO23123618007
MITSUBISHIMK326334;MK584503
MITSUBISHIMK326334;MK584503
GMC88936163
IHC595987C1
HINO23123617004
HINO23123626002
GMC15083702
CHEVROLET15253255
GMC15619626;15514492
GMC15619626;15514492
CHEVROLET88936210
IHC588126C1
INTERNATIONAL582029C1
IVECO2996010;7187567
IVECO2996010;7187567
INTERNATIONAL1648517C1
DODGE52013843AB;2608016C1
DODGE52013843AB;2608016C1
WORKHORSEW8006232
WORKHORSEW8003783
INTERNATIONAL508526C2
GM15515789
INTERNATIONAL589868C1
INTERNATIONAL589843C1
GM15514476
SAEGIGANT9267086
GIGAN9267066
IVECO5513AAE555
IVECOHCV2996709
IVECO2996009
IVECO802082N
TOYOTA822201
MERITOR3218N1366
FUWABC8434
MERITOR822512;10016195
MERITOR822512;10016195
ISUZU8980013430
TOYOTA4351237120;4243137041
TOYOTA4351237120;4243137041
TOYOTA4243137040;4351237121
TOYOTA4243137040;4351237121
