ZRT100
1 Year
1 Year
GS, RoHS, CE, ISO9001
New
>40m
>16t
3
Five-Arm
Folding
69m
100 Ton
3500kn.M
7.8m
ZOOMLION
Nude Package
100 ton
Hunan, China
Product Description
China Telescopic Boom Crane Zoomlion 100Ton Heavy Rough Terrain Crane Rt100
Out products:
1) ALL kinds of trucks.
(Dump truck, mining dump truck, tractor truck, truck trailer ,towing truck , water tank truck, concrete mixer truck, oil tank truck, garbage truck, cargo truck, port terminal tractor, refrigerated truck, truck mounted crane, fire truck, suction sewage truck, bus , etc)
2) All kinds of construction machinery.
(Wheel loader, excavator, folklift, cranes, paver, road roller etc.)
Need more information? Just contact me please!
Parameters:
| Item | Unit | Value | |
|---|---|---|---|
| Work performance | Max. rated lift capacity × work radius | kg.m | 100000×3.0 |
| Max. load moment of basic boom | kN.m | 3339 | |
| Max. load moment of fully extended main boom | kN.m | 1388 | |
| Max. lift height of fully extended main boom | m | 45.6 | |
| Max. lift height of jib | m | 63 | |
| Dimensions | Overall dimensions(L×W×H) | mm | 14247×3620×3960 |
| Outrigger spread (L×W) | mm | 8000×7900 | |
| Main boom length (Fully retracted fully extended) | mm | 10800-34000 | |
| Jib length (Jib section 1,jib sections 1+2) | mm | 10000-17000 | |
| Boom angle | ° | -3 - 78 | |
| Swing range | ° | 360 360° unlimited swing(Full range) | |
| Work Speeds | Max. hoist rope speed (Main winch) | m/min | 126 |
| Min. boom extend time | s | 170 | |
| Min. boom retract time | s | 158 | |
| Min. boom derric up time | s | 82 | |
| Min. boom derric down time | s | 69 | |
| Swing speed | r/min | 0-1.5 | |
| Hydraulic system | Rated work pressure | MPa | 30 |
| Rated work oil flow | L/min | 500 | |
| Hydraulic oil tank capacity | L | 1200 | |
| Mass | Complete vehicle mass | kg | 65000 |
| Front axle load | kg | 33200 | |
| Rear axle load | kg | 31800 | |
| Travel | Max. travel speed (Forwarsd / backwards) | km/h | 24/15 |
| Wheelbase | mm | 4600 | |
| Treads (Front / rear) | mm | 2860 |
