Feasures
Long and strong boom system
Four-section boom of high strength steel structure and optimized sexangle cross section reduces weight significantly with higher safety rates.
Jib mounting angles are 0°, 15°, and 30° which ensures fast and convenient change-over between different operating conditions so as to improving working efficiency of the machine.
Energy-saving hydraulic system
Triple gear pump, load feedback and constant power control are applied to provide strong lifting capacity and good micromobility.
Unique steering buffer design is applied to ensure stable braking operation.
Safety devices
The load moment limiter equipped with the comprehensive intelligent protection system is used with accuracy within 3% to provide a comprehensive logic and interlock control, thus ensuring more safe and reliable operation.
Parameters
| Capacity | Max. lifting capacity | 60 ton |
| Dimensions | Overall length | 13700 mm |
| Overall width | 2750 mm | |
| Overall height | 3750 mm | |
| Axle distance-1,2 | 1450 mm | |
| Axle distance-2,3 | 4200 mm | |
| Axle distance-3,4 | 1350 mm | |
| Weight | Overall weight | 42000 kg |
| Front axle load | 16000 kg | |
| Rear axle load | 26000 kg | |
| Engine | Rated power | 250 kW/ 2100 rpm |
| Rated torque | 1425 N.m/ 1200-1500 rpm | |
| Traveling | Max. traveling speed | 83 km/h |
| Min.turning radius | 11 m | |
| Min.turning radius of boom head | 14 m | |
| Drive train | 8 × 4 | |
| Min. ground clearance | 295 mm | |
| Approach angle | 19° | |
| Departure angle | 14° | |
| Max. gradeability | 42% | |
| Fuel consumption per 100km | ≤ 43 L | |
| Main Performance | Temperature range | -20 ºC - + 40 ºC |
| Min.lifting radius | 3 m | |
| Tail swing radius of superstructure | 4.065 m | |
| Boom section | 5 | |
| Boom shape | U-shaped | |
| Max. lifting moment-Base boom | 2009 kN·m | |
| Max. lifting moment-Full-extend boom | 1050.6 kN·m | |
| Max. lifting moment-Full-extend boom+jib | 521.1 kN·m | |
| Length-Base boom | 11.3 m | |
| Length-Full-extend boom | 43.5 m | |
| Length-Full-extend boom+jib | 59.5 m | |
| Outrigger span(Longitudinal/Transversal) | 6 × 7.2 m | |
| Jib offset | 0 ° 15 ° 30 ° | |
| Working Speed | Max. single rope lifting speed of main winch (no load) | 125 m/min |
| Max. single rope lifting speed of auxiliary winch (no load) | 125 m/min | |
| Full extend/retract time of boom | 100 / 120 s | |
| Full raise/lower time of boom | 60 / 80 s | |
| Swing speed | 0~2 r/min | |
| Aircondition | HVAC in low cab | Heating/Cooling |
| HVAC in up cab | Cooling |
