EJC215
1 Year
1 Year
Adjustable
Stacker
AC Motor
1T - 5T
Electric
500mm
3000~5000mm
New
Stacker
1500kg
Warehouse Material Handling
PU Wheel
Customized Color
GP
Standard
610kg
China
8427109000
Product Description
1) electric power steering system, light and low noise
2) drive unit floating bodies with patent design
3) AC driving system, no carbon brush, maintenance free
4)USA CURTIS controller,German REMA handler,Imported electrical components.
5)Electromagnetic braking system
6)stepless speed control system
7)controller with automatic protection
8)emergency reversing device/ emergency brake switch
9)Integrated hydraulic and power control system, easily operation, reliable performance
10)Brake effect when handler at highest and lowest position.
11) More safety with double limit switch when lift
| model | EJC215E-330 | |
| operating type | walkie | |
| power source | battery | |
| load capacity | Kg | 1500 |
load center | mm | 600 |
| wheel type | PU | |
| service weight | kg | 610 |
| Wheel dimension(driving wheel/balance wheel/bearing wheel) | mm | φ210x70/φ115x55/φ80x70 |
| wheel base | mm | 1146.5 |
Wheel quantity(driving wheel/balance wheel/bearing wheel) | pcs | 01/1/4 |
Operate handle(highest/lowest) | mm | 1185/840 |
| Overall length/width | mm | 1696/790 |
Fork dimensin(thickness/width/length) | mm | 50/160/920 |
Width between forks(inside/outside) | mm | 295/555 |
| min.ground clearance | mm | 30 |
| fork lift height | mm | 3300 |
| min.turning radius | mm | 1325 |
Min.aisle width for pallets | mm | 2018 |
Gradeability(laden/unladen) Travel speed(laden/unladen) | % Km/h | 5/7 3.5/4.0 |
Lift speed(laden/unladen) | mm/s | 110/160 |
Lowering speed(laden/unladen) | 155/170 | |
Brake type | Electromagnetic | |
| drive motor(DC) | Kw | 0.75 |
| lift motor(DC) | Kw | 2.4 |
battery voltage | V | 24 |
| battery capacity | Ah | 110×2 |
