ESG110-116
20 Years
2 Years
Adjustable
Full Electric Pallet Stacker
AC Motor
1T - 5T
Electric
>500mm
3000~5000mm
New
Optional
1270
PU
Curtis
GP
Nude Packing
China
842720900
Product Description
ESG115
Main features
Main features
1) Electronic power steering system, light and low noise
2) Drive unit floating bodies with patent design
3) AC driving system, no carbon brush, maintenance free
4)USA CURTIS controller, German REMA handler, imported waterproof electrical components
5)Electromagnetic braking system
6)Stepless speed control system, safe and quiet
7)controller with automatic protection
8)Emergency reversing device
9)Integrated hydraulic and power cntrol system, easily operation, reliable performance.
10)Brake effect when handler at highest and lowest position
| Item | Feature | |||||
| 1 | Model | ESG110 | ESG112 | ESG115 | ESG116 | |
| 2 | Type | Narrow legs | Narrow legs | Narrow legs | Narrow legs | |
| 3 | Mast type | 2-Stage STD | 2-Stage STD | 2-Stage STD | 2-Stage STD | |
| 4 | Load capacity | kg | 1000 | 1200 | 1500 | 1600 |
| 5 | Load center | mm | 600 | 600 | 600 | 600 |
| 6 | Wheel base | mm | 1270 | 1270 | 1325 | 1325 |
| 7 | Operating type | Walkle/Stand on | Walkle/Stand on | Walkle/Stand on | Walkle/Stand on | |
| 8 | Wheels | |||||
| 9 | Wheel type | PU | PU | PU | PU | |
| 10 | Wheel quantity driving wheel/Balance wheel/Bearing wheel | 1/2/4 | 1/2/4 | 1/2/4 | 1/2/4 | |
| 11 | Demension | |||||
| 12 | Standard lift height | mm | 3000 | 3000 | 3000 | 3000 |
| 13 | Lowered fork height | mm | 85 | 85 | 85 | 85 |
| 14 | Fork size(length/width/thickness) | mm | 1150(1200)/180/60 | 1150(1200)/180/60 | 1150(1200)/180/60 | 1150(1200)/180/60 |
| 15 | Overall length | mm | 1940/2413 | 1940/2413 | 1940/2360 | 1940/2360 |
| 16 | Overall width | mm | 812 | 812 | 850 | 850 |
| 17 | Outside with between legs | mm | 570/600/650/685 | 570/600/650/685 | 570/600/650/685 | 570/600/650/685 |
| 18 | Inside with between legs | mm | 180/230/280/315 | 180/230/280/315 | 180/230/280/315 | 180/230/280/315 |
| 19 | Min.turning radius | mm | 1525/1935 | 1525/1935 | 1630/1990 | 1630/1990 |
| 20 | Min.aisle width for pallets 800×1200 | mm | 2130/2520 | 2130/2520 | 2180/2580 | 2180/2580 |
| 21 | Min.aisle width for pallets 1000×1200 | mm | 2160/2540 | 2160/2540 | 2210/2600 | 2210/2600 |
| 22 | Min.groud clearance | mm | 30 | 30 | 30 | 30 |
| 23 | Performance | |||||
| 24 | Travel speed,laden/unladen | km/h | 5/5 | 5/5 | 5/6 | 5/6 |
| 25 | Lift speed,laden/unladen | mm/s | 110/130 | 110/130 | 95/130 | 90/130 |
| 26 | Travel speed,laden/unladen | mm/s | 120/110 | 120/110 | 110/100 | 110/100 |
| 27 | radeability,laden/unladen | % | 5/7 | 5/7 | 5/8 | 5/8 |
| 28 | Electric configuration | |||||
| 29 | Drive motor /Lift motor/Steering motor | kw | AC1.2/DC2.2/DC0.15 | AC1.2/DC2.2/DC0.15 | ||
| 30 | Battery voltage | V | 24 | 24 | AC1.5/DC3.0/DC0.15 | AC1.5/DC3.0/DC0.15 |
| 31 | Battery capacity | Ah | 2*100 | 210 | 24 | 24 |
| 32 | Brake | Electromagnetic/Regenerative | Electromagnetic/Regenerative | 240 | 280 | |
| 33 | Controller | CURTIS | CURTIS | |||
| 34 | Weight | |||||
| 35 | Battery weight | kg | 150 | 200 | 235 | 235 |
| 36 | Service weight with battery | kg | 1010 | 1110 | 1190 | 1220 |
