1.Modular Trailer
2.Windmill Trailer
3.Normally Trailer as customized design
Detail picture show:
Detail specification:
Telescopic Trailer, Wind Blade Trailer is special design for wind blade transportation;
Length can be Max Extendable to 55 Meters, 3 Meters Width with Air Suspension;
Hydraulic Steering and Wired Remote Control;
Generally it can be 3 axle and 4 axle, we use YUEK Brand Axle, 10.00R20 Tire;
Capacity can be 40Tons;
360° Rotary Windblade Fixing Dolly+Lowbed Semi Trailer | |||||
Model | STA9350EXTL | ||||
Dimension(Optional) | Axle No. | Rated Load (kg) | Tire No. | Tire Size | |
Dimension Made by Customer Machine Size, Standard Length is 13500mm (contact supplier for more) | 1 | 20 | 4 |
8.25R20 10.00R20 11.00R20 12.00R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier) | |
2 | 40 | 8 | |||
3 | 60 | 12 | |||
4 | 80 | 16 | |||
5 | 100 | 20 | |||
Manufacture | Qingdao Eleph Industry & Trade Co., Ltd | ||||
Wheel Base (mm) | 1310 | ||||
leaf-spring Pcs | 10 | ||||
Axle | 13/16/18 T | ||||
Suspension | Heavy Duty Mechanic Suspension with Leaf Springs | ||||
Main Beam Material | Q345B manganese plates, automatic submerged arc welded | ||||
Brake System | Dual line braking system with automatic braking system/chambers | ||||
Kingpin | 2' or 3.5' Interchangeable | ||||
Landing gear | 28T loading capacity with 80T static lifting capacity. | ||||
Platform | 4-6 mm diamond steel plate | ||||
Brake System | Dual Lines Braking System With Automatic Air Chambers | ||||
Electrical System | 24V, 7core socket, lights according to European standards. | ||||
Mainbeam Size | Upper plate | 14mm | |||
Lower plate | 16mm | ||||
Mid Web | 8 mm | ||||
Height | 500-520mm | ||||
Color and Logo | Depends on the buyer's requirement. | ||||
Pin Height | According to the height of the tractor saddle. | ||||
Painting | Three coats painting; Any color will be available | ||||
Various axle steering systems can be used:
Rigid Axles;
Friction-Steered axles;
Knuckle-Steering (hydraulic) axles;
Pendle Axles;
Application:
HEAVYDUTY TRANSPORER TRAILER is suitable for the transportation of the following:
Wind power plants (tower segments, rotor or turbine blades)
Structural elements (steel and concrete elements)
Roof constructions
Bridge elements
Other bulky goods and long material
