Pressure Transducer 100PSI 1/8NPT Pneumatic pressure sensor for Air Compressor Truck Fuel Oil Brake Water
High quality 0 - 150 PSI (0 - 10 BAR) REVELTRONICS pressure sensor with linear voltage output. Commonly used as oil pressure sensor or fuel pressure sensor. Working with automotive gauges and data-loggers (as a pressure sender / transducer) such as UTCOMP & UTCOMP-PRO, AEM EMS, GReddy e-MANAGE, Motec, Stack, ACR systems, HRC etc. Waterproof connector is included with sensor.
• Good stability, high performance price ratio, strong anti-interference frequency converter;
• Compact structure, light weight, easy installation and vibration resistance;
• Ceramic core, suitable for most medium;
• Maximum use temperature: 85 degrees;
• The shell is 304 stainless steel.,special used for no corrosive gas,liquid pressure measurement.
• Waterproof grade: IP65;
Technical Parameter:
1. Connector: 1/8,1/4
2. Working Voltage: 12-24VDC
3. Voltage Output: 0.5-4.5v
4. Working Pressure Range:200PSI / Customized
5. Max Pressure:3.0MPa
6. Compressive failure:4.0MPa
7. Load Impedence:<500Ω
8. Working Temperature Range:-20~85ºC
9. Storage Temperature Range::-20~85ºC
10. Overall Accuracy:+1.0%FS
11. Insulating Strengh:>50MΩ/500V
12. Seal Grade:IP65
13. Cycle Life:1,000,000
Output:
| U(V) | P(psi) | P(bar) |
| 0.5 | 0.00 | 0.00 |
| 1.0 | 18.75 | 1.29 |
| 1.5 | 37.50 | 2.59 |
| 2.0 | 56.25 | 3.88 |
| 2.5 | 75 | 5.17 |
| 3.0 | 93.75 | 6.46 |
| 3.5 | 112.5 | 7.76 |
| 4 | 131.25 | 9.05 |
| 4.5 | 150.00 | 10.34 |
Packaging type:
| VPC Box | White Box | Color Box | VPC Carton | Pallet |
Delivery time:
| conventional products | customized products | specially customized products |
| on the day of payment | 10 workdays | 25 workdays. |
Payment term:
| Paypal | TT | Western Union | DP | LC | Money Gram | Online Bank | Alibaba credit order | Pay later | DA |
| YES | YES | YES | NO | NO | YES | YES | YES | YES | YES |
Transportation:
Express(DHL,UPS,TNT,JCEX,FEDEX) is available.
Sea and Air transports are available.
The most suilable transport way will be chosen for you.
