Veinasa-THPRWU-02
ABS Shell
DC7-30V
RS485 (Modbus Protocol)
Screw Installation;Casing Installation, etc.
-30~80ºC
About 4 M
82mm X (105-222) mm
0.38 Kg
IP65, Rain Proof Outdoor Available
Veinasa
Covered with Carton Package
82 mm x (105-222) mm
China
Product Description
| Veinasa-THPRWU-02 Ultrasonic Compact Rs485 Barometer Professional Wifi Automatic Wireless Weather Station Temperature Sensor for Sale |
Veinasa-THPRWU-02 Ultrasonic Compact Rs485 Barometer Professional Wifi Automatic Wireless Weather Station Temperature Sensor for Sale is a compact ultrasonic weather station integrated features 7 kinds of important meteorological elements. It adopts the principle of ultrasonic measurement and radar detection , through the special calculation method (algorithm), can avoid the sonicc error caused by the temperature change.
This compact ultrasonic weather station can simultaneously output wind speed, wind direction, temperature, humidity, atmospheric pressure, rainfall and ultravoilet radiation.
It can be used in conjunction with a computer, data collector, or other acquisition device that has a communication format consistent with that provided.
| Power supply | 7-30 v DC |
| Signal output | RS485 (Modbus protocol) |
| Average power consumption | 1.7 W |
| Installation | Screw installation;Casing installation, etc. |
| Working temperature | -30~80ºC |
| Standard cable length | About 4 m |
| Size | Φ 82 mm x (105-222) mm |
| Weight | 0.38 kg |
| Material | ABS shell |
| Protection grade | IP65, rain proof outdoor available |
| Sensor Measurement Parameters Table | |||
| Measuring range | Accuracy | Resolution | |
| Wind speed | 0 to 40 m/s | ±3% | 0.01 m/s |
| Wind direction | 0-359 ° | Plus or minus 3 ° | 1 ° |
| Temperature | - 40 ºC to + 80 ºC | ±0.5 ºC | 0.1 ºC |
| Humidity | 0-100% | ±3% | 1 |
| Air pressure | 300-1100 hpa | ±3% | 0.1 hPa |
| Rainfall | 0 to 8 mm/min | ±10% (@ wind speed ≤5m/s) | 0.1 mm |
| Cumulative rainfall | 0-6550 mm | ±10% | 0.1 mm |
| Fall down | 0 - 8 | 1 | 1 |
| UV radiation | 0-400mW/m2 | 10% | 1 |
Characteristics of Veinasa-THPRWU-02 Ultrasonic Compact Rs485 Barometer Professional Wifi Automatic Wireless Weather Station Temperature Sensor for Sale:
1.High integration but small size,
2.Light weight and durability
3.No moving parts, no maintenance and on-site calibration.
Besides, the campact ultrasonic weather station can integrate light, PM2.5/PM10 so it can measure more parameters.
We can customize products according to your needs.
This is professional weather station manufacturer/factory. What we bring you?
1. Rooted in meteorological field over 15+ years
2. Experienced and professional R&D team
3. Every Products verified by CE, ROHS, tested by professional testing institute with Calibration Report.
4. Perfect after-sale service (replied in 24 hours), OEM and customization available
5. 5 years' on-site installation, training and technical support experience in various cases;
6. 30+ patents obtained
Application fields of Veinasa-THPRWU-02 Ultrasonic Compact Rs485 Barometer Professional Wifi Automatic Wireless Weather Station Temperature Sensor for Sale:
* City environmental monitoring
*Agricultural automatic meteorological station
*Traffic automatic meteorological station along the highway
* Meteorological field monitoring station
* Automatic weather station nearby high-voltage transmission substation or guyed
* City environmental monitoring
*Agricultural automatic meteorological station
*Traffic automatic meteorological station along the highway
* Meteorological field monitoring station
* Automatic weather station nearby high-voltage transmission substation or guyed
Q: Are you a factory/manufacturer?
A: Yes, we are professional factory/manufacturer of weather station and relative weather sensors. We also have hot sale and widely used weather station THPRW-03.
Q: What's the main characteristics of this Ultrasonic weather station?
A: Congratulations, it's no moving parts and maintenance-free, factory price but amazing quality.
Q: Can it add/integrate other parameters?
A: Yes it can add/integrate other parameters like PM2.5, PM10, etc,.
Q: What's the common power supply and signal output?
A: Common power supply and signal output is DC7V-30V, RS485. But we can customize for you as demands.
Q: How can I collect data?
A: If you have your own data logger, you only need to buy our sensor and meanwhile we send you communication protocol.
If you do not have, we can add our data logger for you, also provided with English software, which can help you read, inquire and download data.
Q: What's the lifetime of this Ultrasonic weather station?
A: At least 5 years long. Every sensor has its own calibration certificate or testing report.
Q:What's the delivery time?
A: Usually, we dispatch goods in 3-5 working days after receiving your payment. But it depends on your quantity.
Q: May I know your warranty?
A: Yes, usually it's 1 year. We can send you detailed warranty document if needed.
With rich experiences in tackling problems, Veinasa aims to provide a package of meteorological solutions to your needs, whatever problems you encounters, Veinasa team always stand by your side.
Just click the below picture to send us inquiry, to know more, or get the latest catalogue and competitive quotation. Do not hesitate!
