Veinasa-GZY01
Veinasa
Covered with Carton Package
China
Product Description
Veinasa-GZY01 Factory Price Solar Energy Tracker Spectrometer Sun Tracking Sensor without Scattering Radiation Sensor
Veinasa-GZY01 Factory Price Solar Energy Tracker Spectrometer Sun Tracking Sensor without Scattering Radiation Sensor can be used as a
primary standard direct radiation meter. Suitable for all kinds of harsh environments. Fast response and accurate automatic
tracking. The tracking modes of the Solar Tracking System are sensor tracking and sun tracking. Sensor tracking mode is a
real-time sampling by photoelectric converter, computer analysis and comparison of changes in solar light intensity, thus driving
the mechanical mechanism to achieve solar tracking mode. Direct radiation tracking is more accurate.The direct radiometer is a
first-class standard radiometer for measuring the radiation perpendicular to the sun's surface.It conforms to the international
standards of ISO9060 (solar energy, hemispherical solar radiation meter and direct solar meter).
Installation hole spacing:95*95
Installation aperture diameter:φ 8.5
Veinasa-GZY01 Factory Price Solar Energy Tracker Spectrometer Sun Tracking Sensor without Scattering Radiation Sensor can be used as aprimary standard direct radiation meter. Suitable for all kinds of harsh environments. Fast response and accurate automatic
tracking. The tracking modes of the Solar Tracking System are sensor tracking and sun tracking. Sensor tracking mode is a
real-time sampling by photoelectric converter, computer analysis and comparison of changes in solar light intensity, thus driving
the mechanical mechanism to achieve solar tracking mode. Direct radiation tracking is more accurate.The direct radiometer is a
first-class standard radiometer for measuring the radiation perpendicular to the sun's surface.It conforms to the international
standards of ISO9060 (solar energy, hemispherical solar radiation meter and direct solar meter).
Automatic tracking parameters | |
Tracking accuracy | 0.5 degree |
load | 10kg |
Working temperature | -40 C -50ºC |
power supply | DC12V |
Technical indicators of direct radiation tables | |
Spectral range | 300~3000nm |
Measuring range | 0~2000W/m2 |
Sensitivity | 7~14μV/W.m-2 |
Tracking accuracy | <168h±1° |
Time constant | less than 15S (99%) |
Open angle | 4 degrees |
Annual stability | + 1% (sensitivity rate) |
Internal resistance | about 80 ohms |
Power supply mode | DC12V (for automatic tracking device) |
Output signal | 0 ~ 20mV (with DL-2 standard current transmitter can output 4 to 20mA) |
Measurement accuracy | worksheet < 5% |
standard table | < 2% |
Length of instrument | Standard: 2 meters. Other |
Working environment | 45 ~ 45ºC, humidity < 100% RH |
cable grade | Rated voltage:300v,temperature grade: 80ºC |
product weight | 5Kg |
Product power consumption | 50mW |
Installation hole spacing:95*95Installation aperture diameter:φ 8.5
Q: Are you a factory/manufacturer?
A: Yes, we are a professional factory/manufacturer of ultraviolet sensor . We also have hot
sale and widely used solar ridiation sensor Veinasa-ZFS02 .
sale and widely used solar ridiation sensor Veinasa-ZFS02 .
Q: What are the power supply output and common signal output?
A: The common power supply output and signal output are 12VDC
and RS485 respectively. But we can customize for you as demands.
and RS485 respectively. But we can customize for you as demands.
Q: How can I collect data?
A: If you have your own data logger, you only need to buy our sensor and meanwhile we send you communication protocol. If you do not have, we can add our data logger for you, also provided with English software, which can help you read, inquire and download data.
Q: What's the lifetime of this Solar Pyranometer 4-20 mA Total Radiation Sensor?
A: At least 5 years long. Every sensor has its own calibration certificate or testing report.
Q:What's the delivery time?
A: Usually, we dispatch goods in 3-5 working days after receiving your payment. But it depends on your quantity.
Q: May I know your warranty?
A: Yes, usually it's 1 year. We can send you detailed warranty document if needed.
