Veinasa-Qjs Online No Maintenance Self-Cleaning Automatic Electric Cleaning Brush for Do ORP pH Sensor Water Quality Tester

Product detail

Model NO.:

Veinasa-QJS

Operating Temperature:

-5-50ºC

Power Supply:

12-24VDC

Cable Specifications:

Φ6mm, 4 Core, 5m Can Be Customized

Dimensioon:

85mm×85mm×20mm

Power Consumption of The Work:

0.1W@12V

Cable Length:

Φ6mm, 4 Cores, 5m (Customizable)

Trademark:

Veinasa

Transport Package:

Covered with Carton Package

Specification:

85mm× 85mm× 20mm

Origin:

China

Product Description

Veinasa-QJS Online No Maintenance Self-cleaning Automatic Electric Cleaning Brush for Do ORP PH Sensor Water Quality Tester

Veinasa-QJS is an on-line self-cleaning brush that is reliable and easy to use. Up to 4 digital sensors can be installed at the same time, with options for dissolved oxygen, pH, ORP, conductivity, turbidity and other parameters.

Veinasa-QJS on-line self-cleaning bursh is equipped with automatic cleaning device, which consists of built-in motor drive circuit, position detection circuit, DC motor and cleaning brush. Automatic cleaning device can effectively remove the sensor surface stains, prevent the attachment of microorganisms, greatly reduce the maintenance cost. The upper end of the cleaning bracket is designed with 3/4 "NPT thread for easy installation.

Operating temperature	-5~50ºC
Power supply	12~24VDC
Cable specifications	Φ6mm,4 core,5m(Can be customized)
Take up the space	85mm×85mm×20mm
The power consumption of the work	0.1W@12V

Cleaning bracket effect drawing Install sensor effect drawing

Features of Veinasa-QJS:

1.Buying a self-cleaning device effectively cleans the sensor's surface, preventing microbial adhesion and costing less maintenance.

2.Optional installation of dissolved oxygen, conductivity, turbidity, pH, ORP and other sensors, suitable for long-term online monitoring.
3.4 digital sensors can be installed at the same time to measure five parameters.
4.Customers can be installed according to the actual needs of the application of air jet pipeline, spray pipe, ultrasonic cleaning head, sodium hypochlorite generator (seawater antifouling).

Note:

The default cleaning revolution is 3 turns for each side and the cleaning interval is 30 minutes.

When the sensor is installed, it is advisable for the cleaning brush to just touch the surface of the sensor measurement area. If the distance is too close, the cleaning brush will crush the measurement area for a long time, which may lead to scratches on the surface of the measurement area. If the distance is too far, the cleaning effect is not good.
