SM41B
Cantilever Type
Resistance Strain
4-Wire
Digital Type
SemiConductor
Normal Wirewound
Stainless Steel
IP67
ISO
Customized
10t - 50t
GB/T 7551-2008 Certificate
Sun-Moon
Stendard Package
Export
China
9031809090
Product Description
Description:
The sensor is made of alloy steel.
Bridge structure, good resistance to lateral forces and impact resistance.
Execution standard :
GB/T 7551-2008 Certificate
(eqv OIML R60)
Application situation :
Truck scales, track scales, storage scales, etc.
Sealed to IEC 529:
Protection grade:IP67 .Protection against total
immersion in water for 30minutes
at a pressure corresponding to mhead of water.
The sensor is made of alloy steel.
Bridge structure, good resistance to lateral forces and impact resistance.
Execution standard :
GB/T 7551-2008 Certificate
(eqv OIML R60)
Application situation :
Truck scales, track scales, storage scales, etc.
Sealed to IEC 529:
Protection grade:IP67 .Protection against total
immersion in water for 30minutes
at a pressure corresponding to mhead of water.
| Rated Load | 5t~15t |
| Rated Output | 2.0mv/v |
| Total Error | ±0.03F.S |
| Insulation Impedance | ≥5000MΩ |
| Safe Overload | 150% |
| Zero Balance | ±1%F.S |
| Input Impedance | 770±5Ω |
| Output Impedance | 700±2Ω |
| Temperature Effect On Load | ±0.02%F.S/10k |
| Temperature Effect On Zero | ±0.02%F.S/10k |
| Ultimate Overload | 200% |
| Operating Temperature Range | -30ºC~70ºC |
| Recommended Excitation Voltage | 5V~18V(AC or DC) |
| Maximum Excitation Voltage | 24V(AC or DC) |
| Construction | Alloy Steel |
| Protection Class | IP67/ IP68 |
