SM40G
Column Cylinder Type
Resistance Strain
4-Wire
Switching Type
SemiConductor
Normal Wirewound
Stainless Steel
IP67
ISO
Customized
12000kg
GB12602-2009
2.5(24VDC)
120%Fs
Sun-Moon
Stendard Package
Export
China
9031809090
Product Description
Description:
The three-pulley sensor is designed with alloy steel, and when installed, just install the force device on the wire rope. The product can be applied to hook rope without fixed head of tower crane or single rate working condition of truck crane, mine lifting, bridge rope tension monitoring, cable tension monitoring and other equipment, especially in the crane industry is very widely used, especially suitable for wire rope tension detection under dynamic conditions.
characteristic :
Good mechanical and mechanical properties. Small in size and light in weight,
Dimensions (In mm. 1mm=0.03937 inches)
Electrical wiring:
Technical Specification
| Parameter | Min | Type | Max | Unit |
| Maximum Capacity | 12000 | Kg | ||
| Excitation voltage | 13.2 | 24 | 36 | V DC |
| Power Dissipation | 2.5(24VDC) | W | ||
| Signal output | Three wire system4~20(mA) | |||
| Combined Error | ±0.5 | %FS | ||
| Creep over 30 min 30 | ±0.3 | %FS | ||
| Temperature effect | ±0.3 | %FS/10ºC | ||
| Service Temperature Range | -30 | 25 | 70 | ºC |
| Storage Temperature Range | -40 | 25 | 85 | ºC |
| Safe load limit | 120 | %FS | ||
| Lateral load limit | 150 | %FS | ||
| Degree of protection according to EN60529 | IP 67 | |||
| Material:Measuring element | Alloy steel | |||
| Citation Standard | GB12602-2009 | |||
Company Profile
The SUNMOON was founded in 1988. In 1995, the first batch of High-tech enterprises were recognized as national state-level. The SUNMOON also passed the certification of ISO 9001 Quality Management System,ISO14001 Environmental Management System and OHSAS 18001 Occupational Health and Safety Assessment Series. With SM series of products measuring instruments manufacturing license qualification and a variety of explosion- proof measurement and control products production qualification,mechanical and electrical equipment installation engineering professional contracting qualification. With independent intellectual property rights of the patented technology189terms. These is the SUNMOON's core competitiveness of the technology.
The subject positioning classification of the SUNMOON's products is "Sensing and loT Technology"-sensor manufacturing and sensor application technology, information acquisition and processing technologies,loT technology and applications.These is the pioneer of modern high technology.
The SUNMOON products are positioned to "reliably and steadily meet the harsh environment of the industrial site". The whole products system with forward-looking technology, application is convenient, the configuration is universal, now has more than 9000 number of clients from all walks of life. Have SM series weighing, load, pressure, torque, displacement, velocity, temperature and humidity sensors and the corresponding transmitter or amplifier, an annual output of 300 thousand units; an annual output of 20 thousand sets of all kinds of instrument; all kinds of projects completed 2000 terms of the annual capacity.
The SUNMOON take Nanjing City as a scientific research base, making full use of Nanjing's talent advantage and international interests.With Bengbu City covers an area of 50,000 m'as the production and after-sales service base, and with local service as the goal, all the branches in different parts of the Country have jointly formed a complete scientific research, production and after-sales service system platform, which guarantees that The SUNMOON are in the lead of science and technology, innovation and forever the first. These is the SUNMOON's core competitiveness of the mechanism!
