High Precision S type Load Cell 5-200N stainless steel IP68 For Push-pull force gauge
1. Descriptions
5,10,20,50,100,200N Or Customized S type Load Cell FA301 is a model of our brand FIBOS FA3-Series, S type Load Cell FA301 can be used to measure force 5N,10N,20N,50N,100N,200N or customized capacity, its material we use Stainless steel, we can also customized material.
S type Load Cell FA301 Sensitivity is 2.0±10%mV/V, the Zero Balance is ±0.02mV/V.
S type Load Cell FA301 creep(30min) ≤0.05%F.S.. The non-linearity ≤0.05%F.S.. Hysteresis ≤0.05%F.S.. Repeatablity ≤0.05%F.S..
S type Load Cell FA301 Input impedance is 650/350±5Ω, the output impedance is 650/350±5Ω.
S type Load Cell FA301 Temp.effect on output is 0.05%F.S./10ºC, Temp.effect on zero is 0.05%F.S./10ºC.
S type Load Cell FA301 Insulation Resistance ≥5000MΩ/100V(DV).
S type Load Cell FA301 Recommended Excitation is 5V, the Maximum Excitation is 15V.
S type Load Cell FA301 Compensated Temp Range is -10~60ºC, the Operating Temp Range is -20~80ºC.
S type Load Cell FA301 safe overload is 150%F.S.. The ultimate overload is 200%F.S..
The cable size is ∅2*3000mm.
The weight is 0.2kg or customized.
2. Specifications
| Product name | S type Load Cell |
| Capacity | 5,10,20,50,100,200N or customized |
| Rated output | 2.0±10%mV/V |
| Zero Balance | ±0.02mV/V |
| Creep(30min) | ≤0.05%F.S. or customized |
| Non-linearity | ≤0.05%F.S. or customized |
| Hysteresis | ≤0.05%F.S. or customized |
| Repeatability | ≤0.05%F.S. or customized |
| Input impedance | 650/350±5Ω |
| Output impedance | 650/350±5Ω |
| Temp.effect on output | 0.05%F.S./10 ºC |
| Temp.effect on zero | 0.05%F.S./10 ºC |
| Insulation resistance | ≥5000MΩ/100V(DC) |
| Recommended excitation | 5V |
| Maximum excitation | 15V |
| Compensated Temp Range | -10~60 ºC |
| Operating Temp Range | -20~80 ºC |
| Safe overload | 150%F.S. |
| Ultimate overload | 200%F.S. |
| Cable size | φ2x3000mm or customized |
| Weight | 0.2kg or customized |
| Material | Stainless steel or customized |
3. Dimension
Need to be customized
4. Application
5,10,20,50,100,200N Or Customized S type Load Cell FA301 can be used to install and test cell phone components.
Widely used in Push-pull force gauge, hopper scales, various industrial weighing systems, etc.;
Welding force test and tension test, automobile press-fitting, automatic assembly, 3C product testing;
New energy product assembly, medical testing, robot field, mold assembly and other industrial testing, measurement and control systems, with high dynamic response frequency.
Used in a variety of static and dynamic measurement applications. Its high precision makes it suitable for production process monitoring as well as for torque measurement using the lever principle in test stands.
5. Packaging & delivery
Packaging Details
1.Opp bag
2.Custom box
3.According to your request
Port: Shanghai
6. Company
Fibos Measurement Technology (Changzhou) Co., Ltd. is a technical service enterprise specializing in force measurement technology research, product R & D, production, sales and service. It is mainly engaged in micro force sensors, high-precision load cells, S-type sensors, cantilever sensors, multi-dimensional force sensors, tension sensors, transmitters R & D and production of control instruments and provide system engineering control solutions. The company has modern and spacious workshops, high-quality production and testing equipment, professional R & D team and perfect management system to provide reasonable and practical solutions for our customers.
With years of understanding and understanding in the field of automation, the company has always adhered to the enterprise operation concept of "user first", built a professional team in the field of automation, and provided customers with stable quality products and pre-sales and after-sales technical services. We always adhere to the tenet of independent innovation, only good products and scientific management, and always adhere to providing perfect products and system solutions, which is highly respected in our field; Constantly change and provide customers with excellent value-added services.
7. Production
8. Exhibition
9. Certification
10.FAQ
Q1: What is your terms of delivery?
A: EXW, FOB, CFR and CIF.
Q2: Can you produce according to the samples?
A: Yes, we can produce according to your samples or technical drawings.
Q3:What is your sample policy?
A: We can supply the sample with discount if we have ready parts in stock, and customers pay the courier cost.
Q4: What's your quality guarantee policy?
A: Quality guarantee: 12 months.
If the product has quality problem within 12 months, please return it to us, we will repair it, if we can't repair it successfully, we will give you a new one; but the man-made damage, improper operation and force majeure will be excepted.
And you will pay the shipping cost of returning to us, we will pay the shipping cost of delivering to you.
