0.1,0.2,0.3,0.5,1,2,3, 5,10,20,30,50,100,200, 300,500N.m Or Customized Torque Force Sensor FA604
1. Descriptions
0.1,0.2,0.3,0.5,1,2,3, 5,10,20,30,50,100,200, 300,500N.m Or Customized Torque Force Sensor FA604 is a model of our brand FIBOS FA6-Series,
Torque Force Sensor FA604 can be used to measure torque force 0.1N.m, 0.2N.m, 0.3N.m, 0.5N.m, 1N.m, 2N.m,3N.m, 5N.m, 10N.m, 20N.m, 30N.m, 50N.m, 100N.m, 200N.m, 300N.m, 500N.m or customized capacity, its material we use stainless steel, we can also customized material.
Torque Force Sensor FA604 Sensitivity is 1.0~1.5mV/V, the Zero Balance is ±0.01mV/V.
Torque Force Sensor FA604 creep(30min) ≤0.1%F.S.. The non-linearity ≤0.2%F.S.. Hysteresis ≤0.2%F.S.. Repeatablity ≤0.1%F.S..
Torque Force Sensor FA604 Input impedance is 350/700±10Ω, the output impedance is 350/700±10Ω.
Torque Force Sensor FA604 Temp.effect on output is 0.02%F.S./10ºC, Temp.effect on zero is 0.02%F.S./10ºC.
Torque Force Sensor FA604 Insulation Resistance ≥2000MΩ/100V(DV).
Torque Force Sensor FA604 Recommended Excitation is 12V, the Maximum Excitation is 15V.
Torque Force Sensor FA604 Compensated Temp Range is -10~60ºC, the Operating Temp Range is -20~60ºC.
Torque Force Sensor FA604 safe overload is 120%F.S.. The ultimate overload is 150%F.S..
The cable size is 3m.
2. Specifications
| Product name | Torque Force Sensor |
| Capacity | 0.1,0.2,0.3,0.5,1,2,3, 5,10,20,30,50,100,200, 300,500N.m Or Customized |
| Rated output | 1.0~1.5mV/V |
| Zero Balance | ±0.01mV/V |
| Creep(30min) | ≤0.1%F.S. |
| Non-linearity | ≤0.2%F.S. |
| Hysteresis | ≤0.2%F.S. |
| Repeatability | ≤0.1%F.S. |
| Input impedance | 350/700±10Ω |
| Output impedance | 350/700±10Ω |
| Temp.effect on output | 0.02%F.S./10 ºC |
| Temp.effect on zero | 0.02%F.S./10 ºC |
| Insulation resistance | ≥2000MΩ/100V(DC) |
| Recommended excitation | 12V |
| Maximum excitation | 15V |
| Compensated Temp Range | -10~60 ºC |
| Operating Temp Range | -20~60 ºC |
| Safe overload | 120%F.S. |
| Ultimate overload | 150%F.S. |
| Cable size | 3m |
| Material | Stainless Steel or customized |
| IP Class | IP66 |
3. Dimension
Need to be customized
4. Application
0.1,0.2,0.3,0.5,1,2,3, 5,10,20,30,50,100,200, 300,500N.m Or Customized Torque Force Sensor FA604 can be used in the metallurgical powder industry.
The torque force sensor is a sophisticated torque measurement system with wireless power supply and signal transmission. It can accurately measure torque, speed and rotation angle, and provides two signal output modes of voltage and frequency. Precise and reliable, with round shaft ends, it can be easily integrated into various industrial applications, such as end-of-line inspection or development test benches. Standardized design, flexible use, 16 rated ranges can be selected.
5. Packaging & delivery
Packaging Details
1.Opp bag
2.Custom box
3.According to your request
Port: Shanghai
6. Company
Fibos Measurement Technology (Changzhou) Co., Ltd. is a technical service enterprise specializing in force measurement technology research, product R & D, production, sales and service. It is mainly engaged in micro force sensors, high-precision load cells, S-type sensors, cantilever sensors, multi-dimensional force sensors, tension sensors, transmitters R & D and production of control instruments and provide system engineering control solutions. The company has modern and spacious workshops, high-quality production and testing equipment, professional R & D team and perfect management system to provide reasonable and practical solutions for our customers.
With years of understanding and understanding in the field of automation, the company has always adhered to the enterprise operation concept of "user first", built a professional team in the field of automation, and provided customers with stable quality products and pre-sales and after-sales technical services. We always adhere to the tenet of independent innovation, only good products and scientific management, and always adhere to providing perfect products and system solutions, which is highly respected in our field; Constantly change and provide customers with excellent value-added services.
7. Production
8. Exhibition
9. Certification
10.FAQ
Q1: What is your terms of delivery?
A: EXW, FOB, CFR and CIF.
Q2: Can you produce according to the samples?
A: Yes, we can produce according to your samples or technical drawings.
Q3:What is your sample policy?
A: We can supply the sample with discount if we have ready parts in stock, and customers pay the courier cost.
Q4: What's your quality guarantee policy?
A: Quality guarantee: 12 months.
If the product has quality problem within 12 months, please return it to us, we will repair it, if we can't repair it successfully, we will give you a new one; but the man-made damage, improper operation and force majeure will be excepted.
And you will pay the shipping cost of returning to us, we will pay the shipping cost of delivering to you.
