HG-FLS
Tuning Fork Vibrating Level Switch
Contact
Switching Type
Tuning Fork Vibrating Level Switch
Tuning Fork Vibrating Level Switch
Stainless Steel
IP65
CE
Customized
220VAC Standard
110VAC, 24VDC Optional
Relay Output 5A 220VAC
2MPa
-20 - 200 Deg.C
0.5g/cm3
-25 - 60 Deg.C
Aluminum
SUS 304
1.5W
Adjustable
200 Hz
IP65
7s
2s
Siko Instruments
2kg
25*15*15cm
China
9026100000
Product Description
Flange Type 100mm High Temperature Vibrating Tuning Fork Level Switch
HG-FLS series Tuning Fork Level Switch uses the signal of the electronic circuit to excite the crystal in the fork body, so that the fork body of the tuning fork vibrates at a fixed frequency. When the fork body is completely submerged by the material to be tested, the vibration frequency of the fork body occurs Change, the electronic circuit of the instrument will automatically detect this change and convert it into a switch signal output by the relay for on-site alarm or remote control. when the material leaves the fork, the instrument returns to normal working state and continues to detect the change of level.Application:
* Wastewater, Mud, Pulp, Fuel, Aqueous Solution...etc.
* Material Level Control In Power Plants, Steel, Cement And Other Industries.
* Beer, Beer Starter, Beverages And Other Liquids That Will Produce Gas.
| 01. | Top Mounting & Side Mounting. |
| 02. | Compact Design & No Movable Part. |
| 03. | Full Electronic Circuit Design & No Maintenance After Operation. |
| 04. | Wide Range OF Application, And The Physical Properties OF The Materials Will Not Affect The Performance. |
| 05. | Automatic Cleaning Function To Prevent The Materials Hanging. |
