FFGR-620
Intensity Modulation
Physical Properties Fiber Optic Sensor
Digital Type
Integration
Functional
Stainless Steel
IP67
CE
Customized
Fiber Optic Sensors
M6
Diffuse Reflective
1.0mm
1m Cable, Free Cutting
R25
80-100mm
CE, ISO9000
Yes
-25 to 70 Degree
7days After Payment Done
FF-403
F&C
White Box
140g
China
9001100090
Product Description
High Temperature FFGR-620 350 Degree Glass Optical Fiber Integrated Tail Bracket M6 Fiber Sensor
| Type | Model | Head | Fiber optic cable | Convex tube | Wire length | Detection distance | MDO | High temperature resistance |
| High temperature resistant Fiber Optic Sensor | FFGR-810-4.7 (Tail plug:Φ4.7) | M8 | Φ7.3×3.2 | / | 1m | 100mm | Φ0.5 | -40ºC~350ºC |
| FFGR-810U-4.7 (Tail plug:Φ4.7) | M8 | Φ7.3×3.2 | / | 1m | 100mm | Φ0.5 | -40ºC~350ºC | |
| FFGR-610 | M6 | Φ2.9×1.1 | / | 2m | 80mm | Φ0.05 | -40ºC~350ºC | |
| FFGR-620 | M6 | Φ2.9×1.1 | / | 2m | 80mm | Φ0.05 | -40ºC~350ºC | |
| FFGR-620-I | M6 | Φ2.9×1.1 | Φ2.0×10mm | 2m | 80mm | Φ0.05 | -40ºC~350ºC | |
| FFGR-620-S | M6 | Φ2.9×1.1 | Φ2.0×20mm | 2m | 80mm | Φ0.05 | -40ºC~350ºC | |
| FFGR-620-M | M6 | Φ2.9×1.1 | Φ2.0×40mm | 2m | 80mm | Φ0.05 | -40ºC~350ºC | |
| FFGR-620-L | M6 | Φ2.9×1.1 | Φ2.0×90mm | 2m | 80mm | Φ0.05 | -40ºC~350ºC | |
| FFGR-38MGJC-1M (Integrated tail bracket limited reflection type, special for glass detection) | / | / | / | 1m | / | / | 250ºC |
- 23+ years manufacture and 10+ years OEM service sensor experience.
- 4000+ models Sensors
- Long service time, 8+ years
- Fast delivery time. Most delivery within 1 days (Stocks)
- IP67 protection grade
- CE, RoHS certification
