B313-C
S Type
Resistance Strain
5 Wires
Analog Type
Miniature Size
Normal Wirewound
Stainless Steel
IP67
RoHS
Customized
17*6.8*19.1mm(L*W*H)
2.5n to 1000n
bransensor
Carton Box
Analog mini load cells
China
8423900000
Product Description
1. Product Name: Brans B313-C miniature stainless steel force sensors and micro S load cells
2. Material and Capacity: 17-4PH stainless steel with 2.5N to 1000N capacity
3. Datasheet:
Brans could OEM and make miniature load cells and force sensors according to most of our clients' requirements. All of these mini-load cells could be made with 17-4PH high grade stainless steel and beautiful outlook and good performance.
Let's work together with Brans to build more perfect wighing products.
2. Material and Capacity: 17-4PH stainless steel with 2.5N to 1000N capacity
3. Datasheet:
| Number | Specifications | Technique |
| 1 | Capacity | 2.5,5,10,20,50,100,200,300,500,1000,2000N |
| 2 | Rated output | 2.0±10%mV/V |
| 3 | Zero balance | ±0.02 mV/V |
| 4 | Non-linearity | 0.05%F.S. |
| 5 | Hysteresis | 0.05%F.S. |
| 6 | Repeatability | 0.05%F.S. |
| 7 | Creep(30min) | 0.05%F.S. |
| 8 | Temp.effect on output | 0.05%F.S./10ºC |
| 9 | Temp.effect on zero | 0.05%F.S./10ºC |
| 10 | Input impedance | 350±30Ω |
| 11 | Output impedance | 350±5Ω |
| 12 | Insulation | ≥5000MΩ/100VDC |
| 13 | Recommended excitation | 5V |
| 14 | Maximum excitation | 15V |
| 15 | Compensated temp range | -10~60ºC |
| 16 | Operation temp range | -20~80ºC |
| 17 | Safe overload | 150%F.S. |
| 18 | Ultimate overload | 300%F.S. |
| 19 | Cable size | φ2×4000mm |
| 20 | Weight approx. | 0.1kg |
| 21 | Material | Stainless Steel |
| 22 | IP Class | IP66 |
Brans could OEM and make miniature load cells and force sensors according to most of our clients' requirements. All of these mini-load cells could be made with 17-4PH high grade stainless steel and beautiful outlook and good performance.
Let's work together with Brans to build more perfect wighing products.
