kmm1318i
1year
New
1
Trailer
ISO
Steel
Semi-Trailer
13t 16t
Black or as Requested
420*180/200/220
8*M20*285 / 10*M22*335
Jap ISO
Square & Round
JLB
One 20 Feet Container Can Load 58 PCS
ISO9001&TS16949
Qingdao, China
871690
Product Description
American type inboard axle for trailer
High quality & best price
CE: ISO9001: 2008 ISO / TS16949: 2009
Manufacturer
We can produce as to your requirements
High quality&best price
Introduction of enterprise:
Qingdao Jinlibo Trade Co., Ltd. Has introduced sophisticated equipment from overseas to develop and manufacture semi-trailer axles and related parts. Holding ISO9001: 2000 certification for our management system, we faithfully follow the stipulations of this standard so as to guarantee high product quality.
Characteristics:
1. Special heat-treat, low-alloy steel axle beam, it has the vitues of good synthetic performance, strong load ability and lower self weight.
2. High quality alloy solid inserted spindle, through wholy heat treatment, provide superior fatigue capability.
3. High performance premium non-asbestos brake linings, estend serbice life.
4. Easy for ABS installation.
5. Camshaft, matching with special seals, can ensure no entry of the grease into the brake drum, more safety.
6. New tight fit hub cap habe O rings, high property for sealing.
7. Grease lubricant is supplied by Mobil that lengthens the time of free maintenance.
8. Full range of stud fixing such as ISO, BSF and JAP, it can meet the requirements of various wheel rims.
Scope of our business
1. Axles (German type axle, English type axle, American type axle, Spoke axle, ZM axle, Agriculture axle, Half axle, Axle without brake)
2. Suspension (Bogie suspension, One point suspension, Rigid suspension, Spoke suspension, Machinery suspension)
3. Landing gear
4. Fifth wheel (2'' 3.5'')
5. King pin (2'' 3.5'')
6. Semi trailer
7. Other axles and related parts (Low bed axle, hub, rims, spring, drum...)
American Type Inboard Axle
| AXLE TYPE | BRAKE SIZE | WHEEL FIXING | NO.XSIZE OF WHEEL STUD | WHEEL REG.DIA | DIM D | BEARING | WHEEL RIM SIZE | BEAM SIZE | AXLE CAPACITY | SPRING SEAT INSTALLATION | TRACK LENGTH | WEIGHT |
| KMM1318I | 420*180 | ISO | 10*M22*335 | 281 | 725 | 518445 518445 | 20'' | S150 | 13T | ≤450 | 1840mm | 372KG |
| KMM1320I | 420*200 | ISO | 10*M22*335 | 281 | 735 | 518445 518445 | 20'' | S150 | 13T | ≤450 | 1840mm | 385KG |
| KMM1322I | 420*220 | ISO | 10*M22*335 | 281 | 745 | 518445 518445 | 20'' | S150 | 13T | ≤450 | 1840mm | 408KG |
| KMM1318Q | 420*180 | JAP | 8*M20*285 | 221 | 725 | 518445 518445 | 20'' | S150 | 13T | ≤450 | 1840mm | 372KG |
| KMM1318J | 420*180 | JAP | 8*M20*285 | 221 | 725 | 518445 518445 | 20'' | S150 | 13T | ≤450 | 1840mm | 372KG |
| KMM1622I | 420*220 | ISO | 10*M22*335 | 281 | 748 | 518445 220149 | 20'' | S150 | 16T | ≤450 | 1850mm | 430KG |
| KMM1620I | 420*200 | ISO | 10*M22*335 | 281 | 738 | 518445 220149 | 20'' | S150 | 16T | ≤450 | 1850mm | 420KG |
| KMM1618I | 420*180 | ISO | 10*M22*335 | 281 | 728 | 518445 220149 | 20'' | S150 | 15T | ≤450 | 1850mm | 415KG |
| KMMR1318I | 420*180 | ISO | 10*M22*335 | 281 | 725 | 518445 518445 | 20'' | R127*19 | 13T | ≤450 | 1840mm | 372KG |
| KMMR1320I | 420*200 | ISO | 10*M22*335 | 281 | 735 | 518445 518445 | 20'' | R127*19 | 13T | ≤450 | 1840mm | 385KG |
| KMMR1322I | 420*220 | ISO | 10*M22*335 | 281 | 745 | 518445 518445 | 20'' | R127*19 | 13T | ≤450 | 1840MM | 408KG |
| KMMR1318J | 420*180 | JAP | 8*M20*285 | 221 | 725 | 518445 518445 | 20'' | R127*19 | 13T | ≤450 | 1840mm | 372KG |
| KMMR1318IQ | 420*180 | ISO | 10*M22*285.75 | 221 | 725 | 518445 518445 | 20'' | R127*19 | 13T | ≤450 | 1840mm | 372KG |
| KMMR1622I | 420*220 | ISO | 10*M22*335 | 281 | 748 | 518445 220149 | 20'' | R127*25 | 16T | ≤450 | 1850mm | 430KG |
| KMMR1620I | 420*200 | ISO | 10*M22*335 | 281 | 738 | 518445 220149 | 20'' | R127*25 | 16T | ≤450 | 1850mm | 420KG |
| KMMR1618I | 420*180 | ISO | 10*M22*335 | 281 | 728 | 518445 220149 | 20'' | R127*25 | 15T | ≤450 | 1850mm | 415KG |
