LI-ION-DYS-22.2V-2.0A-1
Lithium-Ion Battery Pack
for Dyson
Chargeable
High Discharge Rate
Medium
Battery
>1000MAH
>12V
Battery for Vacuum Cleaner
Li-ion
1 Year
Ceba, Samsung, Panasonic, LG, SANYO
Acceptable
Grey
EnnoTool
Standard Packing, Paper Box; Wooden Box
/
China
Product Description
Li-ion 21.6V 3000mAh Battery for Dyson DC31, DC35 type B, DC44 Animal, DC45, DC31, DC31 Animal, DC34, DC35, DC35 Animal, DC35 Exclusive
Item | Specifications |
Compatibility | 917083-01, 17083-2811, 18172-01-04, 17083-4211 17083-04 |
Typical Capacity | 1500mAh @ 1C Discharge |
Minimum Capacity | 1425mAh @ 1C Discharge |
Nominal Voltage | 22.2V |
Standard Charge | CC/CV, 300mA, 25.2V |
Standard Discharge | CC, 1C, 18.0V |
End-of-charge Voltage | 25.2V ± 0.3V |
End-of-charge Current | 0.02C (At CV mode) |
End-of-discharge Voltage | 15.0V |
Charging Time | 6 hours (standard charge) |
Standard Discharge Current | 3000mA (1.0C5rate) |
Max Discharge Current | 11.2A |
Operating Temperature | Charging : 0ºC~45ºC Discharging : -20ºC~60ºC |
Storage Temperature | -5ºC~35ºC |
Max Storage Temperature | 65ºC ≤ 30d |
Storage Humidity | ≤ 75% RH |
Standard Environmental Condition | Temperature : 23±5ºC Humidity : 45-75%RH Atmospheric Pressure : 86-106 Kpa |
