NPHG Series is gel batteries. It performs well in both high rate discharge and float service applications. This series is specially designed for UPS standby power supply. It is also available for other float service applications, such as emergency power supply, communication power supply etc. The power of this series is ranged from 35W to 900W.
Koyama® 12V115W high rate gel battery for backup or high efficientcy UPS 12V28Ah/10HRPhysical Specification
Nominal Voltage:12V
Rated Power:115W/15 min
Nominal Capacity (10HR):28AH
Length:165mm
Width:126mm
Container Height:174mm
Total Height:174mm
Weight:8.7kg
Standard Terminal:T3
Container Material:ABS
Features:
- 10 year design life @ 25ºC
- High energy, high intensity, high quality output electrical energy product series.
- Gel-batteries are designed to be operated within a wide temperature range -40ºC and +55ºC.
- Same volume same quality level can advance high energy output density for an increase of 20%.
- It is best suited for high rate intensice applications and high efficient UPS.
- High rate discharge construction.
- Deep discharge recoverability.
- Patented long life alloy having the lowest calcium levels in the industry- minimizing grid growth, reducing gassing, and extending battery life.
- Patented UL recognized flame-arresting vents in each cell for safety and long life.
- Can be operated in any orientation. Upright, side or end mounting recommended.
- When it is used in safe surroundings, the battery is maintenance free, and you never need to add water, it can be recycled repeatedly.
- Not restricted for air transport - Complies with IATA/ICAO special provisions A67.
- Not restricted for surface transport - Classified as non-hazardous material as related to DOT-CFR title 49 parts171-189.
- Not restricted for water transport - Classified as non-hazardous material per IMDG amendment 27.
Applications:
- Data Centers
- Network Operations Centers
- Industrial Process Control Facilities
- Internet Housing Sites
- Semiconductor Manufacturing
- Banks & Financial Markets
- Power Generation Plants
- Hospitals & Testing Laboratories
The main model list of our EVF batteries for deep cycle application:
| 4. NPHG Series-High Rate Gel Battery for High Efficiency UPS | ||||||||
| Model No | Rated Power(W/Cell) | Capacity (Ah) | Dimension | Weight | Terminal Type | |||
| Length | Width | Height | Total Height | kg | ||||
| mm | mm | mm | mm | |||||
| NPHG35-12 | 35/15Min | 8 | 151 | 65 | 94 | 100 | 2.6 | F2 |
| NPHG55-12 | 55/15Min | 12 | 152 | 99 | 96 | 102 | 3.8 | F2 |
| NPHG85-12 | 85/15Min | 20 | 181 | 77 | 167 | 167 | 6.5 | T1 |
| NPHG115-12 | 115/15Min | 28 | 165 | 126 | 174 | 174 | 8.7 | T3 |
| NPHG145-12 | 145/15Min | 34 | 196 | 130 | 155 | 167 | 11.0 | T3 |
| NPHG170-12 | 170/15Min | 42 | 197 | 166 | 174 | 174 | 13.8 | T3 |
| NPHG300-12 | 300/15Min | 80 | 260 | 169 | 211 | 215 | 25.0 | T3 |
| NPHG370-12 | 370/15Min | 95 | 307 | 169 | 211 | 215 | 31.0 | T3 |
| NPHG420-12 | 420/15Min | 110 | 331 | 174 | 214 | 219 | 34.0 | T4 |
| NPHG470-12 | 470/15Min | 135 | 407 | 174 | 210 | 233 | 39.0 | T5 |
| NPHG520-12 | 520//15Min | 150 | 484 | 171 | 241 | 241 | 47.0 | T4 |
| NPHG680-12 | 680/15Min | 170 | 532 | 206 | 216 | 222 | 58.5 | T5 |
| NPHG770-12 | 770/15Min | 220 | 522 | 240 | 219 | 224 | 68.0 | T6 |
| NPHG800-12 | 800/15Min | 230 | 520 | 269 | 204 | 209 | 70.0 | T6 |
| NPHG900-12 | 900/15Min | 255 | 520 | 268 | 220 | 225 | 79.0 | T6 |
| NPHG720-6 | 720/15Min | 180 | 260 | 180 | 247 | 251 | 30.8 | T5 |
