225ah 6V Deep Cycle AGM Battery with Double Terminal for Golf Cart/Sweeper

Product detail

Model NO.:

DC226-6DT

Type:

Lead-Acid Batteries

Usage:

Car, UPS, Electric Power, Lighting, Electric Bicycle, Boat, Marine.Solar

Nominal Voltage:

Discharge Rate:

Low Discharge Rate

Shape:

Square Battery

Electrolyte:

Installation:

Fixed

Rechargeable:

Chargeable

Color:

Black or Any Color You Like

Size:

260*180*246*266mm

Capacity:

226ah

Weight:

30.4kgs

Trademark:

Koyama

Transport Package:

Carton, Then Pallet

Specification:

JIS, DIN, IEC, BCI

Origin:

Guangdong, China

HS Code:

85072000

Product Description

KOYAMA® DC SERIES Deep-Cycle AGM batteries are ideal for applications that require sealed batteries with heavy-duty cycling capabilities or for backup power. Deep-cycle batteries typically feature thick plates with a high-density active material. The thick battery Plates allow for reserve energy to be stored deep within the battery plate and released during slow discharge such as trolling or electronic instrument use. The high-density active material remains Within the batteries 'plate/grid structure longer, resisting the normal degradation found in cycling Conditions. They are typically used where the battery is discharged to great extent and then recharged.

DEEP CYCLE AGM BATTERY

DC226-6DT Deep Cycle AGM Battery

Model No. DC226-6DT
Dimension: 260*180*246*266MM
Terminal: dt
Weight: 30.5kgs
Voltage ( V ): 6V
Rated Capacity ( 10HR, AH ): 226AH
Terminal Type: T5/DT
OEM: OK

MAIN FEATURES:

• High Power Density

•Thick Plates and High-density

• Superior Deep Cycle Design

• High Power Density

•Thick Plates and High-density Active Material

•Excellent energy storage capacity combined with high reliability

•Designed in accordance with IEC 60254-1

•700 Cycles at 75%DOD

APPLICATION:

• Golf car, wheeler, electric vehicle

• Solar energy/ wind power system

• electrical tools

• other power drive equipment, etc

• Golf/NEV/Utility Vehicles

• Aerial Work Platforms/Access

• Floor Machine

• Material Handing

Deep Cycle AGM Model No. List

Model No	Industry No	Rated Voltage(V)	Rated Capacity (Ah)	Dimension				Weight	Terminal Type
				Length	Width	Height	Total Height	kg
				mm	mm	mm	mm	kg
6V DEEP CYCLE AGM BATTERY
DC200-6	/	6	200/20HR	306	168	220	226	30	T5-M8
DC210-6	GC2/T605	6	210/20HR	260	180	246	252	29.5	T5-M8
DC210-6DT	GC2/T605	6	210/20HR	260	180	246	266	29.8	DT-M8
DC220-6	/	6	220/20HR	306	168	220	226	31.5	T5-M8
DC225-6	DIN/TE35	6	225/20HR	243	187	275	275	30.5	T5-M8
DC225-6AP	DIN/TE35	6	225/20HR	243	187	275	275	30.5	AP
DC226-6	GC2/T105	6	226/20HR	260	180	246	252	30	T5
DC226-6AP	GC2/T105	6	226/20HR	260	180	246	268	30	AP
DC226-6DT	GC2/T105	6	226/20HR	260	180	246	266	30.4	DT-M8
DC250-6	T145	6	250/20HR	260	180	265	272	34.2	T5
DC250-6DT	T145	6	250/20HR	260	180	265	285	34.5	DT-M8
DC310-6	902/J305	6	310/20HR	295	178	346	350	46.0	T5-M8
DC310-6DT	902/J305	6	310/20HR	295	178	345	365	46.3	DT-M8
DC330-6	902/J305	6	330/20HR	295	178	346	350	46.6	T5-M8
DC330-6DT	902/J305	6	330/20HR	295	178	345	365	46.9	DT-M8
DC380-6	L16P	6	380/20HR	295	178	404	408	55.1	T5-M8
DC380-6DT	L16P	6	380/20HR	295	178	404	424	55.4	DT-M8
DC420-6	L16H	6	420/20HR	295	178	404	408	56.8	T5-M8
DC420-6DT	L16H	6	420/20HR	295	178	404	424	57.1	DT-M8
8V DEEP CYCLE AGM BATTERY
DC170-8	T875/890	8	170/20HR	260	182	266	271	34.7	T5-M8
DC170-8DT	T875/890	8	170/20HR	260	182	266	286	35.0	DT-M8
DC200-8	GC8H	8	200/20HR	260	182	295	300	38.7	T5-M8
DC200-8DT	GC8H	8	200/20HR	260	182	295	315	39.0	DT-M8
12V DEEP CYCLE AGM BATTERY
DC14-12	N/A	12	14/20HR	152	99	96	102	3.8	F2
DC18-12L	N/A	12	18/20HR	181	77	167	167	5.4	L1/T1-M5
DC20-12L	N/A	12	20/20HR	181	77	167	167	6.0	L1/T1-M5
DC24-12	N/A	12	24/20HR	166	175	126	126	8.3	T2-M5/M6
DC26-12	N/A	12	26/20HR	165	126	174	174	8.0	T2-M6
DC28-12	N/A	12	28/20HR	165	126	174	174	8.4	T2-M6
DC35-12	U1	12	35/20HR	196	130	155	167	10.5	T2-M6
DC40-12	U1L	12	40/20HR	198	166	174	174	14.0	T2-M6
DC48-12	U1L	12	48/20HR	198	166	174	174	14.5	T2-M6
DC55-12	22NF	12	55/20HR	229	138	208	212	16	T3-M6
DC58-12	22NF	12	58/20HR	229	138	208	212	17.5	T3-M6
DC70-12	93	12	70/20HR	350	167	178	178	23.3	T3-M6
DC75-12	24	12	75/20HR	260	169	211	215	25	T3-M6
DC75-12M8	24	12	75/20HR	260	169	211	215	25	T3-M8
DC75-12DT	24	12	75/20HR	260	169	211	231	25.1	DT-M8
DC85-12	24	12	85/20HR	260	169	211	215	26.1	T3-M6
DC85-12M8	24	12	85/20HR	260	169	211	215	26.1	T3-M8
DC85-12DT	24	12	85/20HR	260	169	211	231	26.2	DT-M8
DC90-12	27	12	90/20HR	307	169	211	216	28.2	T3-M6
DC90-12DT	27	12	90/20HR	307	169	211	231	28.3	DT-M8
DC100-12	27	12	100/20HR	307	169	211	216	29.6	T4-M8/M6
DC100-12	27	12	100/20HR	307	169	211	230	30.2	AP
DC100-12DT	27	12	100/20HR	307	169	211	231	30.3	DT-M8
DC110-12	31	12	110/20HR	331	174	214	219	32.8	T4-M8
DC110-12AP	31	12	110/20HR	331	174	214	231	32.8	AP
DC110-12B	31	12	110/20HR	328	172	215	222	32.5	T4-M8
DC110-12BAP	31	12	110/20HR	328	172	210	238	32.5	AP
DC110-12BAP	31	12	110/20HR	328	172	210	235	32.7	DT-M8
DC110-12DT	N/A	12	120/20HR	407	173	208	233	39.2	T5-M8
DC135-12	G12/J150	12	135/20HR	341	173	283	287	40.8	T5-M8/M6
DC135-12AP	G12/J150	12	135/20HR	341	173	283	302	40.8	AP
DC135-12B	DIN-5SHP	12	135/20HR	341	173	281	281	40.8	T4-M8/M6
DC135-12BAP	DIN-5SHP	12	135/20HR	341	173	281	284	40.8	AP
DC150-12	N/A	12	150/20HR	484	171	241	241	45.5	T4-M8
DC150-12B	T1275	12	150/20HR	328	182	264	271	43.7	T5-M8
DC180-12	4D	12	180/20HR	532	206	215	219	56	T4-M8
DC200-12	4D	12	200/20HR	532	206	216	222	58.4	T5-M8
DC215-12DT	921	12	215/20HR	381	179	350	370	61.5	DT-M8
DC215-12BDT	921	12	215/20HR	381	179	350	370	61.5	DT-M8
DC220-12	8D	12	220/20HR	522	240	219	223	65	T5-M8
DC240-12	8D	12	240/20HR	520	269	203	207	71.0	T5-M8
DC260-12	8D	12	260/20HR	520	268	220	224	77	T5-M8

Replace By Lithium Type Motive Battery-Can Customized--Click Picture to know more
Product Specification

Golf Cart Lithium Battery Parameters
Parameters	51.2V/105AH	51.2V/160AH	76.8V/105AH
Nominal Voltage (V)	51.2	51.2	76.8
Nominal Capacity (Ah)	105	160	105
POWER (KWh)	5376	8192	8064
Dimensions	Customized On Demand
Weight (Kg)	40	60	58
Operating Voltage (V)	44~58.4	44~58.4	66~87.6
Charging Voltage (V)	58.4	58.4	87.6
Recommended Charge Current (A)	≤55	≤80	≤55
Rated Operating Current (A)	≤105	≤160	≤105
Max Operating Current (A)	150	200	230
Charging Temperature (ºC)	0~55
Discharging Temperature (ºC)	-20~55
Storage Temperature (ºC)	0~45
Chemical System	Lithium-iron Phosphate
Warranty	Warranty For 5 Years Or 10,000 Hours Of Service
Available Models	Golf Cart/Sightseeing vehicle

Replace By VRLA Type DCG series Deep Cycle Battery DCG225-6/DCG226-6 -Click Picture to know more

Model No	Industry No	Rated Voltage (V)	Capacity (Ah)	Dimension				Weight	Terminal Type
				Length	Width	Height	Total Height	kg
				mm	mm	mm	mm	kg
6V DEEP CYCLE GEL BATTERY
DCG200-6.pdf	N/A	6	200	306	168	220	222	30.1	T5/AP
DCG210-6.pdf	GC2/T105	6	210	260	180	247	252	29.6	T5/AP
DCG220-6.pdf	N/A	6	220	306	168	220	222	31.6	T5/AP
DCG225-6.pdf	(DIN)	6	225	243	187	275	275	30.6	T5
DCG225-6AP.pdf	(DIN)	6	225	243	187	275	275	30.6	AP
DCG226-6.pdf	GC2/T105	6	226	260	180	247	252	30.2	T5/AP
DCG250-6.pdf	GC2/T105	6	226	260	187	265	272	34.7	T5/AP
DCG310-6.pdf	902/J305	6	310	295	178	354	360	46.2	T5
DCG310-6DT.pdf	902/J305	6	310	295	178	354	360	46.2	DT
DCG330-6AT.pdf	902/J305	6	330	295	178	354	360	46.8	T5/DT
DCG380-6.pdf	L16	6	380	295	178	404	410	55.5	T5
DCG380-6DT.pdf	L16	6	380	295	178	404	410	55.5	DT
DCG420-6.pdf	L16	6	420	295	178	404	410	57	T5
DCG420-6DT.pdf	L16	6	420	295	178	404	410	57	DT
8V DEEP CYCLE GEL BATTERY
DCG170-8.pdf	GC8H	8	170	260	182	266	271	34.2	T5
DCG200-8.pdf	GC8H	8	200	260	182	295	301	38.2	T5
12V DEEP CYCLE GEL BATTERY
DCG100-12.pdf	27	12	100	307	169	211	216	30.3	T4
DCG100-12AP.pdf	27	12	100	307	169	211	216	30.3	AP
DCG110-12.pdf	31	12	110	331	174	214	220	33.5	T4
DCG110-12AP.pdf	31	12	110	331	174	214	220	33.5	AP
DCG110-12B.pdf	31	12	110	328	172	217	222	32.8	T4
DCG150-12B.pdf	(DIN)	12	150	328	182	267	272	44.4	T5/AP

Deep Cycle flooded Model No. List-Click Picture to know more

CBB® KOYAMA® Golf, Utility Vehicle And NEV Flooded TUBULAR Deep-Cycle Battery
With more than 20 years of research and development in lead acid batteries, we canfinally provide you for such deep cycle tubular batteries. Our deep cycle batteries cadeliver more performance and value than ordinary batteries with its super heavyduty tubular plate.
The deep cycle battery is flooded and then it needs watering after used to ensure enough water to cover the plates of each battery. The deep cycle battery is mainlyused in golf carts,Scrubber/Sweeper/floor Machine,Richshaw,Tricycle, and otherelectric vehicles.

6/8V VOLT DEEP-CYCLE FLOODED BATTERIES

Model No

BCI

Size

Capacity Minutes

Capacity Amp-hour(AH)

Voltage

Terminal

Dimensions

Weight

@25Amps

@75Amps

inches(mm)

Kgs

5 Hr

10Hr

20Hr

Volt

Type

DRY

T-605

GC2

383

105

175

193

210

1,2,3,4

10.30 (262)

7.13 (181)

11.15 (283)

17.5

T-105

GC2

447

115

185

207

225

10.30 (262)

7.13 (181)

11.15 (283)

19.5

T-125

GC2

488

132

195

221

240

1,2,3,4

10.30 (262)

7.13 (181)

11.15 (283)

21.0

T-145

GC2H

530

145

215

239

260

2,4

10.30 (262)

7.11 (181)

11.90 (302)

24.0

T-875

GC8

295

117

145

155

170

1,2,3

10.21 (259)

7.10 (180)

11.14 (283)

21.0

T-890

GC8H

340

132

155

175

190

1, 2

10.21 (259)

7.10 (180)

11.14 (283)

23.0

T-1275

GC12

280

120

134

150

12.96 (329)

7.10 (180)

11.81 (300)

32.0

ELECTRIC VEHICLES BATTERIES RELATED SERIES-Click Picture to know more

CBB® KOYAMA® DZM Series Battery is specially designed for motive power applications, i.e. electric bikes/scooters, electric tricycles, electric motorcycles and other device require DC power source. The DZM Series adopts international leading technologies to ensure the batteries with features of long cycle life, large current discharge capability, high reliability and safety, and environmental-friendly.

12V E-bike/Scooter Battery
Item no	Model NO	Voltage(V)	Capacity(AH)	L(MM)	W(MM)	H(MM)	TH(MM)	Weight (KGS)
1	6-DZM-12/14	12	12	151	99	98	101	4.1
2	6-DZM-20	12	22.3	181	77	170	171	6.4
3	6-DZM-20	12	23.2	181	77	170	171	6.7
4	6-DZM-20	12	24	181	77	170	171	7
5	6-DZM-32	12	32	265	75	169	169	9.6
6	6-DZM-32	12	32	220	92	175	175	9.6
7	6-DZM-45/48	12	45	222	120	178	178	12.8
8	6-DZM-52	12	52	222	130	177	177	14.3
9	6-DZM-55	12	55	222	155	175	175	15.7

CBB® KOYAMA® EV series Battery is a high performance Deep Cycle Gel battery similar to the DZM but designed for of various types of Electric Vehicles requiring larger capacity batteries than the Koyama DZM series. The EV series consists of 6/12 Volt batteries ranging from 70 Ah up to 285 Ah. The EV series used in recreational vehicles, Golf Carts, Sightseeing vehicles, Cable vehicles, Electric tractors and various other larger Electric powered industrial vehicles

Model No	Rated Voltage(V)	Rated Capacity (Ah)	Dimension				Weight	Terminal
			Length	Width	Height	Total Height	kg
			mm	mm	mm	mm	kg
12V EVF ELECTRIC VEHICLE BATTERY
3-EVF-200	6	200/3HR	260	180	265	272	35	T5
4-EVF-150	8	150/3HR	260	180	280	285	36.5	T5
6-EVF-40	12	40/3HR	198	166	174	174	14.5	T3
6-EVF-70	12	70/3HR	260	168	213	218	24.5	T3
6-EVF-75	12	75/3HR	260	168	213	218	25.5	T3
6-EVF-80	12	80/3HR	260	168	213	218	26.5	T3
6-EVF-100	12	100/3HR	327	172	216	221	34.5	T5
6-EVF-100A	12	100/3HR	327	172	216	221	34.5	T5
6-EVF-100B	12	100/3HR	327	172	216	221	31.5	T5
6-EVF-120	12	120/3HR	406	173	212	217	42	T5
6-EVF-135	12	135/3HR	340	173	280	285	46	T5
6-EVF-150	12	150/3HR	484	171	241	241	51	T5
6-EVF-200	12	200/3HR	521	238	217	222	64	T5

CBB® KOYAMA® Tricycle Battery are Tubular deep cycle battery specially designed for for electric tricycles .It outranks the ordianary battery with great power and reliability. we offer you both dry charged type and wet charged type both .

12 Tubular Deep Cycle Tricycle Battery
MODEL	Rated Voltage	Rated Capacity(AH)		Dimension (mm)				Without acid(kg)	With acid(kg)
MODEL	(V)	5HR	20HR	Length	Width	Height	Total Height	Without acid(kg)	With acid(kg)
6-DG-140	12	70	98	365	175	255	275	20	30
6-DG-150	12	80	112	365	175	255	275	21	31
6-DG-160	12	90	126	365	175	255	275	23	33
6-DG-170	12	100	140	365	175	255	275	25	35
6-DG-180	12	105	147	365	175	275	285	26	36
6-DG-190	12	110	154	365	175	275	285	27	37.5
6-DG-200	12	120	168	365	175	275	285	29	38
Tubular Deep Cycle Battery for heavy Duty Equipments
EBN280-12	12	167	280	520	283	207	230	48	67
EBN260-12	12	175	260	520	283	207	230	46.5	65.5
EBN240-12	12	190	240	520	283	207	230	44	63

Welcome to contact and inquiry about lead acid battery & lithium battery (lifepo4 battery) and any auto parts!

-Golf/NEV/Utility Vehicles
-Aerial Work Platforms/Access
-Floor Machine
-Material Handing
-Marine/Recreational Vehicle
-Transportation
-Renewable Energy
-Car Starting
-Motorcycle Starting
-Forklift
-Solar/Wind power
-Electric Boat

Clik Below application picture to know related Battery Details!

Q1. What is your terms of packing?
1. Standard export carton ,then onto pallets, or neutral package
2. If any special requirements on package , it is negotiable
3. All batteries are inspected carefully by QC before shipment.

Q2. What is your terms of payment? 1. By T/T , 30% T/T in advance,70% before shipment
2. By L/C at sight
3. Western Union, Money gram or cash

We'll show you the photos of the products and packages before you pay the balance.

Q3. What is your trade terms?
EXW, FOB, CFR, CIF.

Q4. How about your delivery time?
1. our lead time is 15-30days on the basis of order quantity after getting 30% deposit
2. if you need samples or small quantity , we can ship battery within 3-7days if we have stock after test is finished.

Q5. How to reach to us?
A: Please contact Ms. Jancy by We Chat / Whats-App:as above detail, or send me Made in China inquiry .
WX:2621326552

Q6. What is your sample policy?
A: We can supply the sample if we have in stock, but the customers have to pay the sample cost and the courier cost.

Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.

Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit.
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

Company history & Product range

CBB Battery Technology Co Ltd is a large modern comprehensive power enterprise, specializing in production, R&D and sales of the full line of lead acid battery; with a factory area of 65mu and production area more than 30000m2.Our production capacity has reached more than 3 million KVAH per year.

We mainly produce VRLA battery, automotive battery, Motorcycle battery, Motive power battery, Tricycle battery, Electric vehicle battery and various plates thereof. All batteries are widely used in UPS, Power station, solar power system, telecommunication, vehicles, boats, motorcycle and other applications. All battery can meet a variety of standby, storage, deep cycle, starting, sports, new energy system and other power requirements.

Send Message

Message Type
*Content
*Your Name
*Tel
*Email
* Captcha

5 star
4 star
3 star
2 star
1 star
