48V60V72V
Lithium-Ion Battery Pack
Series and Parallel
Chargeable
Medium Discharge Rate
Medium
Battery
20ah 30ah 40ah 50ah 60ah 100ah
Electric Scooter
Li-ion
LiFePO4 Battery Pack
3 Years
Marine, Power Tools, Home Appliances,
48V60V72V
20kg
China
>3000cycles
48V 60V 72V
Yes
Wireless Charging, Remote Control, Type C, Flashli
Meddore
Carton Package
305*172*162mm
Kaifeng, China
8504401990
Product Description
Model |
|
Rated Voltage | 48V/60V/72V |
Nominal capacity | 20ah-100ah |
Standard discharge current | 20A |
Max discharge current | 100A |
Standard charge current | 3C |
Fast charge current | 5C |
Over discharge cut off voltage/series | 35.8V - 84V |
Over discharge protection voltage/series | 84V |
Discharge working temperature | -20-60°C |
Charge working temperature | 0-45°C |
Recommended storage temperature | 23±5°C |
Warranty | 3 year |
Charging Modle | Direct charging |
Size | 305*172*162 mm Or Customized |
Customization:(OEM/ODM)
| Mode | Standard volatage | Charging Volatage | Cycle | Standard Capacity(AH) | Size(MM) |
| 48V20AH | 48V | 58.8V | 3000 | 20 | 303*160*178 |
| 48V50AH | 48V | 58.8V | 3000 | 50 | 303*160*178 |
| 48V60AH | 48V | 58.8V | 3000 | 60 | 305*172*162 |
| 48V65AH | 48V | 58.8V | 3000 | 65 | 305*172*162 |
| 48V80AH | 48V | 58.8V | 3000 | 80 | 305*172*162 |
| 60V40AH | 60V | 71V | 3000 | 40 | 342*157*178 |
| 60V60AH | 60V | 71V | 3000 | 60 | 342*157*178 |
| 60V65AH | 60V | 71V | 3000 | 65 | 342*157*178 |
| 60V80AH | 60V | 71V | 3000 | 80 | 342*157*178 |
| 60V100AH | 60V | 71V | 3000 | 100 | 342*157*178 |
| 72V40AH | 72V | 83V | 3000 | 40 | 285*175*180 |
| 72V50AH | 72V | 83V | 3000 | 50 | 319*165*213 |
| 72V60AH | 72V | 83V | 3000 | 60 | 303*225*180 |
| 72V65AH | 72V | 83V | 3000 | 65 | 358*200*223 |
| 72V80AH | 72V | 83V | 3000 | 80 | 358*200*223 |
| 72V100AH | 72V | 83V | 3000 | 100 | 358*200*223 |
