31075N
75ah
3.1V
3c
5c
Cc
3.95V
1.5V
Over 4000 Times
Sodium Ion Battery
0.5c
0.5c
10years
Yes
MD
160.3*118*50.5mm
1.8KG
Guangzhou
8507600090
Product Description
item | 3.1v 75Ah Prismatic Sodium Ion Battery Cell |
Nominal Capacity | 75Ah |
Battery Type | Sodium Ion Battery |
Battery Size | 160.3*118*50.5mm |
Cell Weight | 1.8kg |
Operating Temperature[°C] | -40 ºC-55 ºC |
Cycle Life | ≥4000 cycle |
Standard Charge/Discharge Current | 0.5C |
| Max Continuous Charge Current | 3C |
Max Continuous Discharge Rate | 5C |
Nominal Voltage | 3.1V |
Working Voltage Range | 1.5v-3.95v |
Weight | 1.8±0.2kg |
Certificate | RoHS/UN38.3/MSDS |
Charging Temperature | -20°C-55°C |
Discharging Temperature | -40°C-55°C |
Impedance | ≤3mΩ |
