MR48200
Li-ion Battery
LFP
Yes
Medium
48V
Li-ion
0-50
10+Years
48V
Support
77kg
50ah-200ah
54.75
-20~60
<2000
Remote Control Boat,Remote Control Plane...
15
Square Battery
5%-85%
MD
Wooden Package
610mm*600mm*170mm
Kaifeng
8507600090
Product Description
| Specification | Parameter | ||||
| Battery Model | 48V100Ah | 48V200Ah | 48V300Ah | 48V400Ah | 48V600Ah |
| Battery Type | LiFePO4(BYD/EVE/CATL Cell) | ||||
| Battery Capacity(+25ºC-0.2C)(WH) | 4800WH | 9600WH | 14400WH | 19200WH | 28800WH |
| Voltage Range | 42V-54.75V | ||||
| Maxium continuous charging current | 50A | 100A | |||
| Maxium continuous discharge current | 100A | 200A | |||
| Maxium pulse current | 200A 3S | 400A 3S | |||
| Product Size/Weight | L580*W450*H210mm 57kg | L580*W760*H210mm92.5kg | L580*W760*H210mm122kg | L600*W600*H1200mm240kg | L600*W600*H1600mm365kg |
| Packing Size/Weight | L630*W500*H260mm58.8kg | L630*W810*H260mm95kg | L630*W810*H260mm125kg | L700*W700*H1400mm270kg | L700*W700*H1800mm396kg |
| operating Temperature | (-10ºC-50ºC) | ||||
| Maxium Number Of Parallel Connected | 16P | ||||
| Cycle Life(+25ºC-0.2C) | >6000Times | ||||
| Storage Time Charging | The mormal voltafe is charged once every 3 months,and the voltage of 10V-10.5Vmust be charged the next day. | ||||
| Warranty Peroid | 5years | ||||
| Case Material | Metal | ||||
| Battery Protection | Overcharge protection,overdischarge protection,overcurrent protection,short circuit,overtemperature protection | ||||
| Communication Protocol | LCD/Heating/CAN/485/232 | ||||
| Inverter Connection Brand | Fit more than 90% of the inverter | ||||
| Application | Telecom Power-Post and Telecommunications,Communications,Power Station,Power Transmission,UPS,Computer System,Solar Energy,Wind Energy,Home Energy Storage etc. | ||||
