61K120GU-AF
Industrial, Power Tools
Constant Speed
Three-Phase
YVP Series Frequency Control
Squirrel-Cage
Closed Type
2
Direct on-line Starting
CE, UL, ISO9001 and RoHS
ZD MOTOR
100mm
120W, 140W
110V, 220V, 380V
1350, 2800rpm
3~ 750K
ZDMOTOR
CTN
UL, CE, ISO9001, CCC, RoHS
Cixi, Zhejiang, China
85014000
Product Description
120W 3-Phase Induction Electric AC Gear Motor
Features:
1) Dimensions: 100mm
2) Power: 120W, 140W
3) Voltage: 110V, 220V, 380V
4) Speed: 1350, 2800rpm
5) Reduction ratio: 3~ 750K
Usage:
Our motors can be widely used in medical appliance, packing mechanism, printing mechanism, cup making machine, textile machinery, and so on.
More about our products and company:
our package:
our machines:
our certifications:
Features:
1) Dimensions: 100mm
2) Power: 120W, 140W
3) Voltage: 110V, 220V, 380V
4) Speed: 1350, 2800rpm
5) Reduction ratio: 3~ 750K
Model * Type | Output power W | Voltage V | Frequency Hz | Current A | Starting Torque mN. m | Rated Torque mN. m | Rated Speed r/min | Capacitor μ F | |
Prnion Shaft | Round Shaft | ||||||||
61K120GU-AFJ (61K120A-AFJ) | 61K120GU-AFTJ (61K120A-AFTJ) | 120 | 1ph100 | 50 | 2.1 | 600 | 930 | 1250 | 30.0 |
60 | 2.5 | 750 | 1550 | ||||||
61K120GU-EFJ (61K120A-EFJ) | 61K120GU-EFTJ (61K120A-EFTJ) | 120 | 1ph110 | 60 | 1.70 | 600 | 750 | 1550 | 20.0 |
1ph120 | 1.80 | ||||||||
61K120GU-CFE (61K120A-CFE) | 61K120GU-CFTE (61K120A-CFTE) | 120 | 1ph220 | 50 | 0.95 | 750 | 930 | 1250 | 8.0 |
1ph230 | 0.95 | ||||||||
61K120GU-HFE (61K120A-HFE) | 61K120GU-HFTE (61K120A-HFTE) | 120 | 1ph220 | 60 | 0.95 | 700 | 750 | 1550 | |
1ph230 | 1.0 | ||||||||
61K120GU-SF (61K120A-SF) | 61K120GU-SFT (61K120A-SFT) | 120 | 3ph220 | 50 | 0.75 | 2200 | 890 | 1300 | _ |
60 | 0.70 | 2000 | 730 | 1600 | |||||
Gearhead Type | Gearhead Model | Gear Ratio |
Long Life Low Noise | 6GU*K | 3, 3.6, 5, 6, 7.5, 9, 12.5, 15, 18, 25, 30, 36, 50, 60, 75, 90, 100, 120, 150, 180, 200 |
Usage:
Our motors can be widely used in medical appliance, packing mechanism, printing mechanism, cup making machine, textile machinery, and so on.
More about our products and company:
our package:
our machines:
our certifications:
