52mm, DC motor 40W 60W, 24V DC gear motor
Household Appliances, Car
Driving
CCC
ZD MOTOR
60, 70, 80, 90mm
3W, 6W, 10W, 20W, 40W
110V, 220V, 12 Volt
50Hz, 60Hz
ZDMOTOR
Cnt
CE, UL, ISO9001 and RoHS
Cixi, Zhejiang, China
8483402090
Product Description
Brush/Brushless DC Planetary Gear Motor Technical,52mm, dc motor 40W 60W,24V dc gear motor
Product Description
1.Adopt Dual supporting structure for output shaft so that the max torque of gearbox is increased a lot.
2.Sun wheel and planetary wheel are connected by spline which increase the max torque of gearbox and lengthen the life.
3. We use helical gear at input stage which make the noise low anf run smoothly in high speed.
4.We use rolling pin holder inside planetary wheel.we use rolling pin grinding instead of sliding grinding so the life of gearbox is much longer.
5. Double supporting structure; Internal grinding on inner bore of planetary gears making the inner bore roundness less than 0.003mm;running by rolling instead of sliding; HRC60 gear surface precision scraping;The adopting of all these technoligies ensure the super quiet and steady operating and a long life time over 10000 hours.
SPECIFICATION FOR TRANSMISSION PLANETARY GEAR MOTOR:
Company Information
FAQ
Q: What're your main products?
A: We currently produce Brushed Dc Motors, Brushed Dc Gear Motors, Planetary Dc Gear Motors, Brushless Dc Motors, Stepper motors, Ac Motors and High Precision Planetary Gear Box etc. You can check the specifications for above motors on our website and you can email us to recommend needed motors per your specification too.
Q: How to select a suitable motor?
A:If you have motor pictures or drawings to show us, or you have detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed lifetime and noise level etc, please do not hesitate to let us know, then we can recommend suitable motor per your request accordingly.
Q: Do you have a customized service for your standard motors?
A: Yes, we can customize per your request for the voltage, speed, torque and shaft size/shape. If you need additional wires/cables soldered on the terminal or need to add connectors, or capacitors or EMC we can make it too.
Q: Do you have an individual design service for motors?
A: Yes, we would like to design motors individually for our customers, but it may need some mold developing cost and design charge.
Q: What's your lead time?
A: Generally speaking, our regular standard product will need 15-30days, a bit longer for customized products. But we are very flexible on the lead time, it will depend on the specific orders.
Please contact us if you have detailed requests, thank you !
Product Description
1.Adopt Dual supporting structure for output shaft so that the max torque of gearbox is increased a lot.
2.Sun wheel and planetary wheel are connected by spline which increase the max torque of gearbox and lengthen the life.
3. We use helical gear at input stage which make the noise low anf run smoothly in high speed.
4.We use rolling pin holder inside planetary wheel.we use rolling pin grinding instead of sliding grinding so the life of gearbox is much longer.
5. Double supporting structure; Internal grinding on inner bore of planetary gears making the inner bore roundness less than 0.003mm;running by rolling instead of sliding; HRC60 gear surface precision scraping;The adopting of all these technoligies ensure the super quiet and steady operating and a long life time over 10000 hours.
SPECIFICATION FOR TRANSMISSION PLANETARY GEAR MOTOR:
| CONSTRUCTION: | BRUSH / BRUSHLESS | ||
| MOTOR OUTSIDE DIAMETER: | 32mm / 42mm / 52mm / 62mm / 72mm / 82mm / 105 mm / 120mm | ||
| PLANETARY GEARBOX DIAMETER: | 32mm / 42mm / 52mm / 62mm / 72mm / 82mm / 105 mm / 120mm | ||
| Conventional products:62mm motor match with 62mm gearbox. Customized product: 62mm motor match with 52mm gearbox, 72mm motor match with 120mm gearbox (example) | |||
| VOLTAGE: | 12 V / 24 V / 48 V | ||
| RATED POWER (watts): | 20 / 25 / 40 / 60 / 90 / 120 / 150 / 180 / 200 / 300 ......750(MAX) | ||
| RATED SPEED(rpm): | 450/540/750/1000/1500/2000/2500/3000 (can be customized) | ||
| PROTECTION GRADE: | IP 20 / IP 44 / IP 55 / IP 65 (According to customer request) | ||
GEAR RATIO: | One Stage | Two stage | Three Stage |
| 3.65/5.36/6.55/8.63 | 13.53/18.92/24.65/28.05/33.92/44.69/58.22 | 67.08......392.98 | |
| High speed | Medium speed | Low speed | |
| Output Torque Range:0.16 N.m---300 N.m ( can be customized) | |||
| SHAFT: | Diameter range:6 mm-32mm, key-way type / D-cut type / Bare type ( can be customized) | ||
| Accessories: | Encoder/ Brake / Connector | ||
Company Information
FAQ
Q: What're your main products?
A: We currently produce Brushed Dc Motors, Brushed Dc Gear Motors, Planetary Dc Gear Motors, Brushless Dc Motors, Stepper motors, Ac Motors and High Precision Planetary Gear Box etc. You can check the specifications for above motors on our website and you can email us to recommend needed motors per your specification too.
Q: How to select a suitable motor?
A:If you have motor pictures or drawings to show us, or you have detailed specs like voltage, speed, torque, motor size, working mode of the motor, needed lifetime and noise level etc, please do not hesitate to let us know, then we can recommend suitable motor per your request accordingly.
Q: Do you have a customized service for your standard motors?
A: Yes, we can customize per your request for the voltage, speed, torque and shaft size/shape. If you need additional wires/cables soldered on the terminal or need to add connectors, or capacitors or EMC we can make it too.
Q: Do you have an individual design service for motors?
A: Yes, we would like to design motors individually for our customers, but it may need some mold developing cost and design charge.
Q: What's your lead time?
A: Generally speaking, our regular standard product will need 15-30days, a bit longer for customized products. But we are very flexible on the lead time, it will depend on the specific orders.
Please contact us if you have detailed requests, thank you !
