Brushless DC motor
Universal, Industrial
Constant Speed
Excited
Control, Driving
Protection Type
4
Brushless
Gdm
ISO9001, CCC, CE, UL
Gpg, Vtv
6W, 10W, 15W, 20W, 40W, 90W, 120W, 200W, 300W
GPG
Carton
G2BLD10-24GN-18S
China
850150
Product Description
TaiBang Motor Industry Group Co., Ltd.
The main products is induction motor, reversible motor, DC brush gear motor, DC brushless gear motor, CH/CV big gear motors, Planetary gear motor ,Worm gear motor etc, which used widely in various fields of manufacturing pipelining, transportation, food, medicine, printing, fabric, packing, office, apparatus, entertainment etc, and is the preferred and matched product for automatic machine.
Motor Model Instruction
G2BLD10-24GN-18S
Motor Performance Parameter
The main products is induction motor, reversible motor, DC brush gear motor, DC brushless gear motor, CH/CV big gear motors, Planetary gear motor ,Worm gear motor etc, which used widely in various fields of manufacturing pipelining, transportation, food, medicine, printing, fabric, packing, office, apparatus, entertainment etc, and is the preferred and matched product for automatic machine.
Motor Model Instruction
G2BLD10-24GN-18S
| G | 2 | BLD | 10 | 24 | GN | 18S |
| Factory Code | Frame Size | Motor Type | Output Power | Power Voltage | Motor Shaft Type | Motor Speed |
| GPG | Motor Mounting Flange: 60mm,70mm,80mm, 90mm,100mm,ø45,ø60 | BLD:Brushless Motor With Square Gearhead BLDP:Brushless Motor With Planetary Gearhead | 10:10W 15:15W 25:25W 40:40W 60:60W 90:90W 200:200W 400:400W | 24:DC24V 36:DC36V 48:DC48V 110:DC110V 220:DC220V | GN:General Bevel Gear GU:Reinforced Bevel Gear A1:Milling Keyway A:Flat type | 15S:1500RPM 18S:1800RPM 25S:2500RPM 30S:3000RPM |
Motor Performance Parameter
| Model | Voltage | Rated Power | No-load Parameter | Load Parameter | Motor Life (Hours) | Motor Weight(kg) | |||
| Rotation Speed | Current(A) | Rotation Speed | Torque(N.m) | Current(A) | |||||
| G2BLD15-24 | 24V | 15W | 2200RPM | Max 0.3 | 1800RPM | 0.05 | 1.1 | >5000 | 0.45 |
| G2BLD15-36 | 36V | 2100RPM | Max 0.2 | 1800RPM | 0.05 | 0.7 | |||
| G2BLD15-48 | 48V | 2100RPM | Max 0.1 | 1800RPM | 0.05 | 0.5 | |||
| G2BLD25-24 | 24V | 25W | 3300RPM | Max 0.4 | 3000RPM | 0.08 | 1.3 | 0.65 | |
| G2BLD25-36 | 36V | 3200RPM | Max 0.3 | 3000RPM | 0.08 | 0.9 | |||
| G2BLD25-48 | 48V | 3200RPM | Max 0.2 | 3000RPM | 0.08 | 0.7 | |||
