42HSL40-1004YAL
3D Printer , Robot ,and So on
Other
Two-Phase
HB-Hybrid
Driving
Other
Other
Linear
Ce / RoHS / ISO9001
Jk
2 Phase
1.8 Degree
3.9V
1.0A
JK
Expert Carton
CE/ROHS/ISO9001
China
8501109990
Product Description
42HSL 42mm linear stepping motor with CE / ROHS
Brand Name: JK
Model Number: JK42HSL
Certification: CE / ROHS / ISO9001
Packaging Details: Export carton
Delivery Time: FOR SAMPLES, 7-10days; For batch. 15-25days.
Payment Terms: T/T, L/C, PAYPAL, Western union
Supply Ability: 100000pcs/month
Item Specifications:
1. NEMA8 Hybrid Stepper Motor
2. Model Number: JK42HSL40-1004YAL
3. Phase: 2 Phase
4. Linear stepper motor
5. Structure: Hybrid
6. Step Angle: 1.8 degree
7. Motor Height: 40mm
8. Current: . 1A
9. Resistance: 3.9Ω
10. Inductance: 8.9 mH
11. Motor Weight: 0.28KG
12. Holding Torque: 8.9 Kg. Cm
13. Speed: Low / High speed
14. Certification: CE, RoHS, ISO9001
15. Shape: Square
16. Applications: Use for robots stepper motor, electronic automatic equipment stepping motor, medical instrument stepping motor, advertisementing instrument stepper motor, lighting& audio equipment stepper motor, printer stepper motor, textile machinery stepper motor. CNC router stepper motor.
| Torque | Mass | |||||||
| Mm/step | (L)mm | V | A | Ω | mH | kg.cm | No. | |
| JK42HSL40-1004YAL | 40 | 3.9 | 1 | 3.9 | 8.9 | 4.8 | 0.28 | |
| JK42HSL34-0804 | 0.01 | 34 | 5.4 | 0.8 | 6.7 | 9.5 | 2.5 | 0.2 |
| JK42HSL40-0406 | 0.02 | 40 | 12 | 0.4 | 26 | 23 | 3 | 0.26 |
| JK42HSL48-0406 | 0.04 | 48 | 12 | 0.4 | 30 | 22 | 3.8 | 0.36 |
