JK60HS67
CNC Machine
Low Speed
Two-Phase
HB-Hybrid
Driving
2
Two Phase
Magnetic-Electric
ISO9001, CCC, Ce, RoHS, SGS
Jkongmotor
Jk60HS
Custom
15n
75n
Custom
80 Degree Max.
0.02mm Max. (450g Load)
0.08mm Max. (450g Load)
20%
Custom
Jkongmotor
Inner Pack and Poly and Master Carton and Pallet
20pcs per carton
Jiangsu Changzhou
8501109990
Product Description
67mm 2phase hybrid stepper motor for cnc machine
General Specification:
Step Angle Accuracy: ±5%
Resistance Accuracy: ±10%
Inductance Accuracy: ±20%
Temperature Rise: 80°C Max
Ambient Temperature: -20°C~+50°C
Insulation Resistance: 100MΩ Min., 500VDC
Dielectric Strength: 500VAC for one minute
Shaft Radial Play: 0.02Max (450g-load)
Shaft Axial Play: 0.08Max (450g-load)
Specification:
| Model No. | Step Angle | Motor Length | Current /Phase | Resistance /Phase | Inductance /Phase | Holding Torque | # of Leads | Mass |
| ( °) | (L)mm | A | Ω | mH | N.m | No. | Kg | |
| JK60HS67-2008 | 1.8 | 67 | 2.0 | 2.4 | 4.6 | 1.5 | 8 | 1.2 |
| 1.8 | 67 | 2.8 | 1.2 | 4.6 | 2.1 | |||
| 1.8 | 67 | 1.4 | 4.8 | 18.4 | 2.1 |
Applications:
Used for robots stepper motor,
electronic automatic equipment stepping motor,
medical instrument stepping motor,
advertising instrument stepper motor,
lighting& audio equipment stepper motor,
printer stepper motor, textile machinery stepper motor.
Cnc router stepper motor.
