86STH96-4508A-03
Printing Equipment
High Speed
Two-Phase
HB-Hybrid
Control, Driving
Other
Three Phase Double Beat
Electromechanical
ISO9001, CCC, RoHS
Other
1.8degree
Square
Black
3.4n.M-13n.M
68-155mm
JK
Export Carton
NEMA34
China
8501109990
Product Description
Descriptions:
| Item | Value |
| Warranty | 1 Year |
| Place of Origin | China |
| Brand Name | Jkongmtor |
| Model No. | JK86HS68-155 |
| Phase | 2 |
| Type | Hybrid |
| Current/Phase | 2.8A-6A |
| Certification | CE, Rohs |
| Holding Torque | 3.4N.m-12.5N.m, |
| Motor Length | 76MM |
| Diameter of Axle | 67-155MM |
| Number of Leads | 4 leads or 8 leads |
| Resistance | 0.28Ω -1.4Ω |
| Inductance | 1.7mH -8mH |
| Shaft Type | D-Cut Shaft or Round Shaft |
| Type | Nema34 Stepper motor |
Product Paramenters:
Step angle:1.8° Temperature rise:below 80 ºC
Ambient temperature:-20 ºC ~ + 50 ºC
Insulation resistance:minimum 100MΩ, 500VDC
Dielectric strength:820VAC for 1 minute
Shaft radial clearance 0.02 max (450 g load)
Shaft axial clearance:0.08Max. (450 g load)
Maximum radial force:220N (20mm from flange)
Maximum axial force:60N
Model Name: JK86HS78-5504
Step Angle(degrees):1.8Degree
Model Number:NEMA34
Phase:2
Type:Hybrid
Current / Phase:5.5A
Resistance:0.46Ω
Inductance:4mH
Holding Torque:4.5N.m
Motor length:78mm
Number of leads: 4leads
Shaft Dia: 12mm or 12.7mm
Shaft Type: Round Shaft or D-cut Shaft
Model Name: JK86HS115-6004
Step Angle(degrees):1.8Degree
Model Number:NEMA34
Phase:2
Type:Hybrid
Current / Phase:6A
Resistance:0.6Ω
Inductance:6.5mH
Holding Torque:8.5N.m
Motor length:115mm
Model Name: JK86HS115-6004
Step Angle(degrees):1.8Degree
Model Number:NEMA34
Phase:2
Type:Hybrid
Current / Phase:6A
Resistance:0.6Ω
Inductance:6.5mH
Holding Torque:8.5N.m
Motor length:115mm
Number of leads: 4leads
Model Name: JK86HS155-6004
Step Angle(degrees):1.8Degree
Model Number:NEMA34
Phase:2
Type:Hybrid
Current / Phase:6A
Resistance:1Ω
Inductance:0.68mH
Holding Torque:12.5N.m
Motor length:155mm
Number of leads: 4leads
Step Angle(degrees):1.8Degree
Model Number:NEMA34
Phase:2
Type:Hybrid
Current / Phase:6A
Resistance:1Ω
Inductance:0.68mH
Holding Torque:12.5N.m
Motor length:155mm
Number of leads: 4leads
Detailed Image:
Company File:
WHY YOU CHOOSE US:
We are a professional manufacturer for Stepper motor , Stepper driver, BLDC motor and DC motor. we can supply OEM service.
Our products all with CE and ROHS.
Welcome you visit our company Changzhou Jingkong Motor&Electric Appliance Co.,Ltd
Depending on advanced technology and knight service, we establish a good and diligent team and keep nice business relationship with a large amount of worthy clients in global market. We are prepared to provide the best products to clients at competitive price.
High quality
Competitive price
Good Packing
Fast Delivery
Knight service
Advanced technology
Believe that we will do our best!
| Model No. | Step Angle | Motor Length | Current /Phase | Resistance /Phase | Inductance /Phase | Holding Torque | # of Leads | Detent Torque | Rotor Inertia | Mass |
| ( °) | (L)mm | A | Ω | mH | N.m | No. | kg.cm | g.cm2 | Kg | |
| JK86HS68-5904 | 1.8 | 67 | 5.9 | 0.28 | 1.7 | 3.4 | 4 | 0.8 | 1000 | 1.7 |
| JK86HS68-2808 | 1.8 | 67 | 2.8 | 1.4 | 3.9 | 3.4 | 8 | 0.8 | 1000 | 1.7 |
| JK86HS78-5504 | 1.8 | 78 | 5.5 | 0.46 | 4.0 | 4.6 | 4 | 1.2 | 1400 | 2.3 |
| JK86HS78-4208 | 1.8 | 78 | 4.2 | 0.75 | 3.4 | 4.6 | 8 | 1.2 | 1400 | 2.3 |
| JK86HS97-4504 | 1.8 | 97 | 4.5 | 0.66 | 3.0 | 5.8 | 4 | 1.7 | 2100 | 3.0 |
| JK86HS97-4008 | 1.8 | 97 | 4.0 | 0.98 | 4.1 | 4.7 | 8 | 1.7 | 2100 | 3.0 |
| JK86HS100-6004 | 1.8 | 100 | 6.0 | 0.36 | 2.8 | 7.0 | 4 | 1.9 | 2200 | 3.1 |
| JK86HS115-6004 | 1.8 | 115 | 6.0 | 0.6 | 6.5 | 8.7 | 4 | 2.4 | 2700 | 3.8 |
| JK86HS115-4208 | 1.8 | 115 | 4.2 | 0.9 | 6.0 | 8.7 | 8 | 2.4 | 2700 | 3.8 |
| JK86HS126-6004 | 1.8 | 126 | 6.0 | 0.58 | 6.5 | 6.3 | 4 | 2.9 | 3200 | 4.5 |
| JK86HS155-6004 | 1.8 | 155 | 6.0 | 0.68 | 9.0 | 13.0 | 4 | 3.6 | 4000 | 5.4 |
| JK86HS155-4208 | 1.8 | 155 | 4.2 | 1.25 | 8.0 | 12.2 | 8 | 3.6 | 4000 | 5.4 |
