86mm 24V 48V Brushless DC Motor BLDC with Planetary Gearbox Jk86bls98-04

Winding type

Delta

Hall effect angle

120 degree electrical angle

Shaft run out

0.05mm

Radial play

0.02mm@450g

End play

0.08mm@450g

Max. radial force

220N @ 20mm from the flange

Max. axial force

60N

Insulation class

Class B

Dielectric strength

500VDC for one minute

Insulation resistance

100MΩMin., 500VDC

Model

JK86BLS58

JK86BLS71

JK86BLS98

JK86BLS125

Number of poles

8

Number of phase

3

Rated voltage         VDC

48

Rated speed           RPM

3000

Rated torque          N.m

0.35

0.7

1.4

2.1

Rated power           W

110

220

440

660

Peak torque           N.m

1.05

2.1

4.2

6.3

Peak current          A

11

19

33

55

Line to line resistance   ohms

1.05

0.36

0.2

0.16

Line to line inductance  mH

2.2

1.05

0.48

0.3

Torque constant        Nm/A

0.1

0.11

0.13

0.11

Back E.M.F            V/KRPM

10.5

11.5

13.5

11.5

Rotor inertia           g.cm²

400

800

1600

2400

Body length (L)        mm

58

71

98

125

Mass                  Kg

1.5

1.85

2.6

4
