Specification:
Descriptions
JK0220 is a type of 2 phase hybrid Stepper motor driver . this driver input DC 12-DC36 Voltage. This kind of drive with advanced pure sine wave current control technology, with large torque, low noise, low vibration and other characteristics, is suitable for the size of 20, 28,35,39,42 and other kinds of phase 2 or 4 phase hybrid stepping motors.
Features
*Average current control,2 phase sinusoidal output current drive
*supply voltage from 12VDC~36VDC and 12VAC~24VAC
*Opto-isolated signal I/O
*Overvoltage, under voltage,overcurrent,phase short cicuit protection
*8 channels subdivision and automatic idle-current reduction
*8 channels output phase current setting
* Can drive 2 phase and 4phase hybrid stepper motor when phase current less than 2.0A
*20KHz PMW.
Mechanical Specification
Input Voltage 12~36V DC,
Output current 0.3A~2.0A
Temperature working temperature -10°~45°,stocking temperature ~20°~70°
Humidity Not condensation , no water droplets
Gas Prohibition of combustible gases and conductive dust
Weight 180g
Switch Choice:
1,Microstepping choice:
| SW5 | On | Off | On | Off | On | Off | On | Off |
| SW6 | On | On | Off | Off | On | On | Off | Off |
| SW7 | On | On | On | On | Off | off | Off | Off |
| Micro | 1 | 2 | 4 | 8 | 16 | 32 | 64 | 128 |
2,Current choice:
| SW1 | On | Off | On | Off | On | Off | On | Off |
| SW2 | On | On | Off | Off | On | On | Off | Off |
| SW3 | On | On | On | On | Off | Off | off | Off |
| Current(A) | 0.3 | 0.4 | 0.5 | 0.6 | 1.0 | 1.2 | 1.5 | 2.0 |
Drawing:
